Xantrex XDL56-4
| Attribute | Value |
|---|---|
| Number of Outputs | 4 |
| Output Voltage Range | 0 – 56 V |
| Output Current Range | 0 – 4 A per channel |
| Maximum Output Power | 224 W total |
| Voltage Regulation (Load) | ≤ 0.01% + 3 mV |
| Current Regulation (Load) | ≤ 0.01% + 3 mA |
| Ripple and Noise (RMS) | ≤ 1 mV RMS |
| Display Type | 4-digit LED display for voltage and current |
| Input Voltage | 115/230 VAC, 50/60 Hz |
| Operating Temperature | 0°C to 40°C |
Xantrex XDL56-4 Options:
- XDL56-4 - HV - Factory set 230 VAC input (internally adjustable)
- XDL56-4 - 56-4P - GPIB, RS-232 and USB interface (P model variant)
| Model | XDL56-4 |
|---|
The Xantrex XDL56-4 is a programmable power supply delivering up to 56V and 4A, designed for precision and reliability. It features a compact design, digital display, excellent regulation, and low ripple output with integrated overload and thermal protection.
Ideal for bench testing, small-scale development, and education, the XDL56-4 ensures stable power delivery and accurate monitoring. Its programmability makes it versatile for sensitive applications requiring consistent performance.
Testwall can supply the used Xantrex XDL56-4, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Xantrex XDL56-4.
