Yokogawa
Yokogawa GS210 DC
Voltage/Current Source.
±30 V (High resolution mode: ±12 V) Output Voltage Range
±200 mA (High resolution mode: ±120 mA) Output Current Range
100 µV (30 V range), 10 µV (high resolution 12 V range) Voltage Resolution
1 µA (200 mA range), 100 nA (high resolution 120 mA range) Current Resolution
±(0.02% of reading + 0.02% of range) Voltage Accuracy
| Attribute | Value |
|---|---|
| Output Voltage Range | ±30 V (High resolution mode: ±12 V) |
| Output Current Range | ±200 mA (High resolution mode: ±120 mA) |
| Voltage Resolution | 100 µV (30 V range), 10 µV (high resolution 12 V range) |
| Current Resolution | 1 µA (200 mA range), 100 nA (high resolution 120 mA range) |
| Voltage Accuracy | ±(0.02% of reading + 0.02% of range) |
| Current Accuracy | ±(0.02% of reading + 0.02% of range) |
| Output Channels | 1 channel (single output) |
| Communication Interfaces | USB, GP-IB (optional), RS-232 (optional), Ethernet (optional) |
| Operating Temperature Range | 5°C to 40°C (41°F to 104°F) |
| Power Supply Requirements | 100–240 V AC, 50/60 Hz, approximately 30 VA |
| Model | GS210 |
|---|
********************************** Please note Input Voltage is set for 100VAC **********************************************
Yokogawa?GS210 DC Voltage / Current Source(front panel output terminals): 32 V, 200 mA
Limitless Applications
- From traditional semiconductor characterization to quantum computing, the GS200 is purposely designed to handle increasingly complex scenarios
- Source and sink in all four quadrants; generate endless combinations of test scenarios
- Generate pulse width modulation, ramp, step, and arbitrary waveforms
- Use as a storage device or integrate into an automated test system
- Upload and download setup files, test patterns, and test results with a simple press of a button
- No programming or software development required
- Featuring extremely low-noise current and voltage sourcing capabilities, the GS200 provides the perfect stimulus whether used for a short while or several days
- Synchronize multiple units to boost voltage or current without losing accuracy or resolution
