Amplifier Research 200T1G3
| Attribute | Value |
|---|---|
| Frequency Range | 10 kHz – 1 GHz |
| Output Power | 200 Watts CW Minimum |
| Gain | 55 dB Minimum |
| Input Power for Rated Output | 100 mW (20 dBm) Maximum |
| Power Supply Voltage | 208/220 VAC, Single Phase, 50/60 Hz |
| Input Impedance | 50 Ohms |
| Output Impedance | 50 Ohms |
| Harmonic Distortion | -10 dBc Maximum (at Rated Output) |
| Cooling Method | Forced Air Cooling |
| Connectors | Input: Type N Female; Output: Type N Female |
Amplifier Research 200T1G3 Options:
- 200T1G3 - E1 - Removable outer enclosure, size 19.8 x 11.7 x 30 in. (50.3 x 29.7 x 76.2 cm); adds 14kg (30 lbs) to weight of E2
- 200T1G3 - E2 - Without outer enclosure, size 19 x 10.5 x 30 in. (48.3 x 26.7 x 76.2 cm); weight 46kg (100 lbs)
- 200T1G3 - E2S - Without outer enclosure; slides and front handles installed for rack mounting; same size as E2, adds 3kg (5 lbs) to weight of E2
- 200T1G3 - S1R - Reflected sample port on rear panel, type N female connector; forward and reflected sample port calibration data supplied on disk in Excel format at 51 points, evenly spaced over the specified frequency range
| Model | 200T1G3 |
|---|
The Amplifier Research 200T1G3 is a broadband, air-cooled traveling wave tube (TWT) microwave amplifier offering 200 watts minimum output across 0.8–2.8 GHz with 53 dB gain. It includes a built-in IEEE-488 interface, VSWR protection, gain control, and monitoring of key parameters such as cathode voltage, helix current, and cabinet temperature. The modular power supply ensures reduced weight and easier maintenance.
Designed for test and measurement, EMC RF susceptibility testing, research, and service applications, the 200T1G3 provides reliable, instantaneous bandwidth with precise AM, FM, and pulse modulation capability.
Testwall can supply the used Amplifier Research 200T1G3, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Amplifier Research 200T1G3.
