Anritsu MS46121A
| Attribute | Value |
|---|---|
| Frequency Range | 1 MHz to 20 GHz |
| Number of Ports | 1-Port |
| Dynamic Range | 120 dB |
| Output Power Range | -45 dBm to +3 dBm |
| Trace Noise (Typical) | 0.004 dB rms |
| Connector Type | 3.5 mm (f) |
| Number of Data Points | 2 to 100,001 |
| Interface | USB 2.0, Ethernet (LAN) |
| Power Supply | USB Bus Powered (5V DC) |
| Operating Temperature | 0°C to +55°C |
Anritsu MS46121A 4 Or 6GHz 1-port USB Vector Network Analyzer Options:
- MS46121A - 002 - Time Domain
- MS46121A - 004 - 40 MHZ To 4 GHZ, 1-Port
- MS46121A - 006 - 150 KHZ To 6 GHZ, 1-Port
- MS46121A - 021 - Scalar Transmission Measurement
| Model | MS46121A |
|---|
The Anritsu MS46121A is a 1‑port USB Vector Network Analyzer available in 4 GHz or 6 GHz frequency options, offering precise S‑parameter measurements with high dynamic range and excellent directivity. It connects via USB to a host PC, delivering lab‑grade RF analysis in a compact portable format.
Perfect for field and production use, the MS46121A supports flexible test configurations and includes intuitive software tools for real‑time data visualization, calibration and analysis on the go.
Testwall can supply the used Anritsu MS46121A, fully tested. With expert support and global delivery, Testwall ensures high‑performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Anritsu MS46121A.
