California Instruments XDS400-37
| Atributo | Valor |
|---|---|
| Potencia de salida | 400 VA |
| Tensión de salida | 0 - 300 V AC |
| Frecuencia de salida | 37 Hz |
| Número de fases | Monofásico |
| Corriente de salida máxima | 1,33 A |
| Tensión de entrada | 115 V AC / 230 V AC |
| Distorsión armónica total (THD) | Menos del 0,5% |
| Interfaz de comunicación | GPIB / RS-232 |
| Dimensiones (An x Al x Pr) | 425 mm x 88 mm x 500 mm |
| Peso | 18 kg |
California Instruments XDS400-37 Options:
- XDS400-37 - -IF - GPIB / IEEE-488 interface programming option
- XDS400-37 - -400 - 400 ±10% volt line to line AC input
- XDS400-37 - -480 - 480 ±10% volt line to line AC input
- XDS400-37 - -AUX - Auxiliary control
- XDS400-37 - -RPV5 - Remote voltage programming, 0-5V
- XDS400-37 - -RPV10 - Remote voltage programming, 0-10V
- XDS400-37 - -RPC5 - Remote current programming, 0-5V
- XDS400-37 - -RPC10 - Remote current programming, 0-10V
| Model | XDS400-37 |
|---|
California Instruments XDS400-37 DC Power Supply
The California Instruments XDS400-37 DC Power Supply is a compact and powerful power supply that can deliver upto 400 volts and 37 amps of continuous power. Despite the high power density of this design, the XDS400-37 provides a low noise, stable output. With excellent output regulation and accuracy, California Instruments XDS400-37 DC Power Supply supports a wide variety of DC power applications including communications, semiconductors, automotive, information technology and industrial.
California Instruments XDS400-37 DC Power Supply is easy to operate with it's simple menu driven operation and familiar rotary controls for setting voltage and current. XDS400-37 comes with Windows GUI software. This GUI program offers additional functionalities like Output Sequencing, Data Logging and Pass/Fail Testing. The standard RS232C serial interface supports remote control of all power supply functions and measurements and allows for easy integration into ATE systems. An optional GPIB interface is available as well. Overall California Instruments XDS400-37 is a reliable and versatile DC Power Supply that can meet the demanding needs of a variety of applications.
Specifications for the California Instruments XDS400-37 DC Power Supply Include:
| Voltage | 0-400 Volts |
| Current | 0-37 Amps |
| Accuracy | 0.5 V |
| RMS Noise | 100mv |
