Espec
Espec SH-662
Temperature & Humidity Chamber, -60C to 150C, 2.2 Cu Ft
-40°C a +150°C Rango de Temperatura
20% a 98% HR Rango de Humedad
600 litros Volumen Interior
900 mm x 900 mm x 740 mm Dimensiones Interiores (An x Al x Pr)
1.380 mm x 1.830 mm x 1.010 mm Dimensiones Exteriores (An x Al x Pr)
| Atributo | Valor |
|---|---|
| Rango de Temperatura | -40°C a +150°C |
| Rango de Humedad | 20% a 98% HR |
| Volumen Interior | 600 litros |
| Dimensiones Interiores (An x Al x Pr) | 900 mm x 900 mm x 740 mm |
| Dimensiones Exteriores (An x Al x Pr) | 1.380 mm x 1.830 mm x 1.010 mm |
| Capacidad de Carga | 100 kg |
| Consumo Eléctrico | 8,5 kVA |
| Tipo de Refrigerante | R-404A / R-23 |
| Sistema de Control | Controlador programable con pantalla táctil |
| Número de Programas Almacenables | Hasta 40 programas con 99 pasos cada uno |
Espec SH-662 Options:
- SH-662 - 220VAC-C - Power plug (220V AC) C type
- SH-662 - CWS - Continuous water supply (connection port with pressure-reducing valve)
- SH-662 - CWS-NV - Continuous water supply (connection port without pressure-reducing valve)
- SH-662 - RTWT - Roof top water tank (effective water volume 5L)
- SH-662 - AWR - Automatic water refill
- SH-662 - WBW - Wet-bulb wick (1 box, 24 wicks, 1 dropper)
- SH-662 - VW - Door with viewing window (LED light, W215×H290mm)
- SH-662 - RVW - Roof top viewing window (effective view W181×D107mm)
- SH-662 - IGD - Inner glass door
- SH-662 - HIP - Hand-in port (inquire for details)
- SH-662 - ACP - Additional cable port (inquire for details)
- SH-662 - CRP-25 - Cable port rubber plug for φ25mm
- SH-662 - CRP-50 - Cable port rubber plug for φ50mm
- SH-662 - CRP-100 - Cable port rubber plug for φ100mm
- SH-662 - CRP-SW - Cable port rubber plug spiral-wrapped plug (5×50×2000mm)
- SH-662 - CRP-FC - Cable port rubber plug for flat cable port
- SH-662 - CRP-50S - Cable port rubber plug for φ50mm with slits
- SH-662 - CRP-100S - Cable port rubber plug for φ100mm with slits
- SH-662 - EZ - EZ connect cable port plug (AC 6 to 24V / DC 1.5 to 60V, 0.1 to 3A)
- SH-662 - SHF - Shelf (18-8 Cr-Ni Stainless steel, 5kg load capacity, 5 stages pitch 50mm)
- SH-662 - SB - Specimen basket (W206×H40×D156mm, 18-8 Cr-Ni Stainless steel)
- SH-662 - COK - Cable organizer kit (cable ties, magnetic cable cover, dew tray)
- SH-662 - NRC - Noise reduction rear cover
- SH-662 - IF-RS485 - Interface RS-485
- SH-662 - IF-RS232C - Interface RS-232C
- SH-662 - IF-GPIB - Interface GPIB
- SH-662 - CC-RS485-5 - Communication cable RS-485 5m
- SH-662 - CC-RS485-10 - Communication cable RS-485 10m
- SH-662 - CC-RS485-30 - Communication cable RS-485 30m
- SH-662 - CC-GPIB-2 - Communication cable GPIB 2m
- SH-662 - CC-GPIB-4 - Communication cable GPIB 4m
- SH-662 - PLR - Paperless recorder (5.7inch color touch panel, temperature & humidity type or temperature type)
- SH-662 - THR - Temperature (humidity) recorder, portable type, dot recording, effective width 100mm
- SH-662 - EOT - External output terminal set (×3) - requires option box
- SH-662 - TROT - Temperature recorder output terminal (wet-bulb temperature)
- SH-662 - TC-2 - Thermocouple 2m (type T, brass ball tip)
- SH-662 - TC-4 - Thermocouple 4m (type T, brass ball tip)
- SH-662 - TC-6 - Thermocouple 6m (type T, brass ball tip)
- SH-662 - DC-5V - Applying DC power supply 5V - requires option box
- SH-662 - DC-12V - Applying DC power supply 12V - requires option box
- SH-662 - DC-15V - Applying DC power supply 15V - requires option box
- SH-662 - DC-24V - Applying DC power supply 24V - requires option box
- SH-662 - DC-48V - Applying DC power supply 48V - requires option box
- SH-662 - OB - Option box (for paperless recorder, external output terminal set, specimen temperature control, DC power supply)
- SH-662 - STC - Specimen temperature control (insulated type) - requires option box
- SH-662 - ECS - Electrostatic capacitance-type humidity sensor control (0 to 100%rh, ±2%rh accuracy)
- SH-662 - AFA - Airflow adjuster (4 levels)
- SH-662 - OCP - Overcool protector
- SH-662 - EDAT - External device alarm input terminal
- SH-662 - DOS - Door opening signal output terminal
- SH-662 - SIL - Status indicator light (up to level 4, pole length 226mm)
- SH-662 - ESP - Emergency stop pushbutton (available with or without guard)
- SH-662 - CDT - Chamber dew tray
- SH-662 - OM-CD - Operation manual CD
- SH-662 - OM-BK - Operation manual Booklet
- SH-662 - RPT - Testing and inspection report
- SH-662 - TD - Test data
- SH-662 - TUM - Temperature & humidity uniformity measurement
- SH-662 - CR - Calibration report
- SH-662 - CC - Calibration certificate
- SH-662 - TSC - Traceability system chart
- SH-662 - TC-CERT - Traceability certificate
- SH-662 - STAND - Stand variation (C/L/M/H type with various configurations - inquire for details)
- SH-662 - R449A - Low GWP refrigerant R-449A (64% GWP reduction vs R-404A)
| Model | SH-662 |
|---|
El Espec SH-662 es una cámara de ensayo ambiental de gran capacidad, diseñada para laboratorios y aplicaciones industriales. Ofrece control preciso de temperatura y humedad con construcción resistente, garantizando resultados consistentes y repetibles.
Con su amplio rango ambiental, el SH-662 permite ensayos de muestras grandes o múltiples, ideal para pruebas de calificación, fiabilidad y resistencia en distintos sectores.
Testwall puede suministrar el Espec SH-662 usado, completamente probado. Con soporte experto y entrega global, Testwall asegura equipos de alto rendimiento. Contáctenos si necesita calibración o reparación del Espec SH-662.
