Exfo
Exfo FTB-5523
PMD Analyzer Module
1250 nm – 1650 nm Rango de longitud de onda
hasta 40 dB Rango dinámico
0,8 m Resolución de punto muerto de evento
4 m Resolución de punto muerto de atenuación
hasta 260 km Rango de distancia máxima
| Atributo | Valor |
|---|---|
| Rango de longitud de onda | 1250 nm – 1650 nm |
| Rango dinámico | hasta 40 dB |
| Resolución de punto muerto de evento | 0,8 m |
| Resolución de punto muerto de atenuación | 4 m |
| Rango de distancia máxima | hasta 260 km |
| Precisión de distancia | ±1 m ± 5 × 10⁻⁵ × distancia |
| Anchura de pulso | 3 ns – 20 000 ns |
| Tipo de conector | FC/APC intercambiable |
| Compatibilidad con plataforma | EXFO FTB-500 / FTB-200 |
| Aplicación principal | Pruebas OTDR para redes de fibra óptica monomodo |
Exfo FTB-5523 Options:
- FTB-5523 - ER - Extended range option (analysis range 0.05 to 200 ps)
- FTB-5523 - 89 - Connector type FC/UPC
- FTB-5523 - 90 - Connector type ST/UPC
| Model | FTB-5523 |
|---|
Housed in the FTB-400 portable platform, the FTB-5523 Polarization Mode Dispersion Analyzer uses a patented approach to measuring PMD of installed links -- amplified or not -- as specified by the TIA's new FOTP-124A standard and according to the generalized interferometric approach (GINTY). It is the only PMD unit in the world to test through EDFAs, which is made possible thanks to the mathematical subtraction of the autocorrelation peak in the interferogram. This also enables the use of any source shape. For the first time, a PMD of zero can be measured as such. PMD is now measured precisely, no more mere assumptions.
