Fluke 6330
| Atributo | Valor |
|---|---|
| Rango de frecuencia | 10 kHz – 2,05 GHz |
| Nivel de salida de RF | -127 dBm a +13 dBm |
| Resolución de frecuencia | 1 Hz |
| Modulación AM | 0% – 99,9% de profundidad de modulación |
| Modulación FM | Desviación de hasta 400 kHz |
| Modulación de fase (PM) | Desviación de hasta 10 radianes |
| Exactitud de frecuencia | ±1 ppm (envejecido a 25 °C) |
| Impedancia de salida | 50 Ω |
| Pantalla | Pantalla LCD retroiluminada |
| Alimentación eléctrica | 90 – 264 V CA, 47 – 63 Hz |
Fluke 6330 Options:
- 6330 - IEEE-488 - IEEE-488 Interface (optional)
- 6330 - 230V - 230 VAC, 50/60 Hz power option
| Model | 6330 |
|---|
FLUKE 6330 Compact Temperature Calibration Baths
The Fluke 6330 Compact Temperature Calibration Bath is a versatile bench-top constant temperature bath ideal for temperature calibration and applications demanding precise temperature stability. It employs an advanced solid-state temperature controller with micro-controller technology to ensure precision thermometer testing, stability and uniformity.
The Fluke 6330 bath offers digital remote communication through standard RS-232 and optional IEEE-488 interfaces. The Fluke 6330 performs reliably across a wide temperature range from 35 °C to 300 °C, with stability and uniformity at 300 °C better than ±0.015 C and ±0.020 C respectively, calibrations can easily be performed at this high temperature with total uncertainty better than ±0.05 C. At lower temperatures, stability and uniformity are even better.
Specifications for the FLUKE 6330 Compact Temperature Calibration Baths Include:
| Temperature Range | 30 C to 300 C |
| Heating Time | 30 C to 300 C (250 min) (oil 5017) |
| Cooling Time | 300 C to 100 C (480 min) (oil 5017) |
| Digital Setting Accuracy | ± 0.5 C |
