Fluke 700P07
| Atributo | Valor |
|---|---|
| Rango de presión | 0 a 300 psi (0 a 2068 kPa) |
| Precisión | ±0,05% del rango total |
| Tipo de presión | Presión manométrica |
| Señal de salida | 4-20 mA |
| Tensión de alimentación | 9 a 32 V CC |
| Temperatura de funcionamiento | -20 °C a 85 °C |
| Conexión de proceso | 1/4 NPT macho |
| Materiales en contacto con el fluido | Acero inoxidable 316L |
| Estabilidad a largo plazo | ±0,1% del rango total por año |
| Grado de protección | IP65 |
Fluke 700P07 Options:
- 700P07 - FLUKE-700PCK - Pressure Calibration Kit: power supply, interface adapter, cables, and Fluke 700PC Pressure Module Calibration software for calibrating pressure modules at your facility
- 700P07 - FLUKE-700PMP - Pressure Pump: hand operated pressure pump providing pressures up to approximately 150 psi (1000 kPa) for calibration and troubleshooting of pressure instrumentation
| Model | 700P07 |
|---|
Fluke 700P07 Gauge Pressure Module
The Fluke 700P07 Gauge Pressure Module allows to measure pressure with the Fluke 700 Series Process Calibrators. It displays pressure readings in any of 10 diffe pressure units specified in the calibrator setup. The pressure module has one pressure fitting and measures pressure with respect to atmospheric pressure. Fluke 700P07 Gauge Pressure Module is highly accurate and easy to operate. The calibrators automatically time-stamp and store all saved measurements, saving time, and eliminating errors associated with making manual notations in the field.
Fluke 700P07 Gauge Pressure Module features internal temperature compensation from 0 °C to 50 °C for full-accuracy performance. The pressure module measures pressure using an internal microprocessor. It receives operating power from and sends digital information to the calibrator. This module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, and a precision pressure source. Rugged urethane molded case of Fluke 700P07 Gauge Pressure Module protects the module from rough handling and harsh conditions.
Specifications for the Fluke 700P07 Gauge Pressure Module Include:
| Resolution | 0.01 / 0.1 |
| Measurement range | 500 psi / 3400 kPa |
| Reference Uncertainty (23 ± 3 °C) | 0.025 |
| Total Uncertainty 1 year | 0.05 |
