Fluke 700PD2
| Atributo | Valor |
|---|---|
| Rango de presión | 0 a 200 psi (0 a 1379 kPa) |
| Tipo de presión | Presión diferencial |
| Exactitud | ±0,05% del fondo de escala |
| Señal de salida | 4 a 20 mA |
| Tensión de alimentación | 12 a 28 V CC |
| Temperatura de funcionamiento | -20 °C a 85 °C |
| Conector de proceso | Conexión de 1/4 NPT macho |
| Materiales en contacto con el fluido | Acero inoxidable 316L |
| Grado de protección | IP65 |
| Compatibilidad | Compatible con módulos de presión Fluke 700 series |
Fluke 700PD2 Options:
- 700PD2 - FLUKE-700PCK - Pressure Calibration Kit (power supply, interface adapter, cables, and 700PC Pressure Module Calibration software)
- 700PD2 - FLUKE-700PMP - Hand operated Pressure Pump, provides pressures up to approximately 150 psi (1000 kPa)
| Model | 700PD2 |
|---|
Fluke 700PD2 Dual Pressure Module
The Fluke 700PD2 Dual Pressure Module allows to measure pressure with the Fluke 700 Series Process Calibrators. It displays pressure readings in any of 10 diffe pressure units specified in the calibrator setup. The pressure module measures positive and negative pressure using an internal microprocessor. It receives operating power from and sends digital information to the calibrator. Fluke 700PD2 Dual Pressure Module features internal temperature compensation from 0 to 50 Degree Celsius for full-accuracy performance. The calibrators automatically time-stamp and store all saved measurements, saving time, and eliminating errors associated with making manual notations in the field.
Fluke 700PD2 Dual Pressure Module has two pressure fittings and measures the difference between the applied pressure on the high fitting versus the low fitting. It functions like a gauge module when the low fitting is open. For best results, it is recommended that the module be pressurized to full scale and then vented to zero pressure (atmosphere) prior to zeroing and making measurements. This module can be calibrated locally using the Fluke 700PCK Pressure Calibration Kit, a PC, and a precision pressure source. Rugged urethane molded case of Fluke 700PD2 Dual Pressure Module protects the module from rough handling and harsh conditions.
Specifications for the Fluke 700PD2 Gauge Pressure Module Include:
| Resolution | 0.0001 / 0.07 |
| Measurement range | 1 psi / 6900 Pa |
| Reference Uncertainty (23 ± 3 °C) | 0.15 |
| Total Uncertainty 1 year | 0.2 |
