Hameg HM8135 RF Synthesizer
100 kHz – 1050 MHz Rango de frecuencia
1 Hz Resolución de frecuencia
-140 dBm a +13 dBm Nivel de salida de RF
0,1 dB Resolución de nivel de salida
50 Ω Impedancia de salida
| Atributo | Valor |
|---|---|
| Rango de frecuencia | 100 kHz – 1050 MHz |
| Resolución de frecuencia | 1 Hz |
| Nivel de salida de RF | -140 dBm a +13 dBm |
| Resolución de nivel de salida | 0,1 dB |
| Impedancia de salida | 50 Ω |
| Modulación AM | 0% – 80%, frecuencia de modulación de 0,1 Hz a 100 kHz |
| Modulación FM | Desviación máxima de 100 kHz, frecuencia de modulación de 0,1 Hz a 100 kHz |
| Estabilidad de frecuencia | ±1 ppm (referencia interna TCXO) |
| Interfaz de control remoto | RS-232 e IEC 625 / IEEE 488 (GPIB) |
| Tensión de alimentación | 230 V AC, 50/60 Hz |
Hameg HM8135 RF Synthesizer Options:
- HM8135 - HO85 - OCXO, temperature stability ±1 x 10⁻⁸ (Installation only ex factory)
- HM8135 - HO880 - Interface IEEE-488 (GPIB), galvanically isolated
| Model | HM8135 |
|---|
Hameg HM8135 3GHz RF-Synthesizer is an exceptional RF-Synthesizer combining fast and easy operation with high performance. It includes excellent specifications, including high frequency stability, fast frequency change response time and repeatable signal output levels.
It provides continuous frequency selectable from as low as 1Hz up to 3.0GHz, with optional gated mode. The instrument offers amplitude, frequency, phase and gated modulation.
Key Features
- Frequency range starting at 1 Hz
- Modulation modes: AM, FM, pulse, ?M, FSK, PSK
- Rapid pulse modulation: typ. 200 ns
- Internal modulator (sine wave, square wave, triangle, sawtooth): 10 Hz to 200 kHz
- 10 configuration memories including turn-on configuration
- Galvanically isolated USB/RS-232 interface optionally IEEE 488 (GPIB)
- Input for external timebase (10 MHz)
- High spectral purity
