SKU
twLR2000
QUADTECH LR2000
The Quadtech LR2000 Milliohmmeter with its LCD display and menu-type front panel programming assures that low resistance measurements on switches, relays, cables, and other devices can be made quickly and easily. With a basic accuracy of 0.05% the instrument offers a wide measurement range from 1μohm to 2Mohms. For remote operation and production applications
the unit comes standard with an RS-232 interface, plus IEEE-488 and handler interfaces are available as options. For measurement integrity,
contact to the test device is made via a 4-terminal Kelvin connection that incorporates an automatic zeroing function to compensate for lead errors.
The Quadtech LR2000 is typically used for the following applications:
-
Production Testing of Contact Resistance of Switches, Relays, Connectors, Cables, and Other Low Resistance Devices
-
Testing of Low Value Resistors, Fuses, Squibs, and Heating Elements
-
Winding Resistance of Motors, Transformers, Solenoids, and Ballasts
-
Conductivity Evaluation in Product Design
-
Incoming Inspection and Quality Assurance Testing
Features and specifications of the Quadtech LR2000 include:
-
1μΩ - 2MΩ Measurement Range
-
1μA - 1A Constant Current
-
0.05% Basic Measurement Accuracy
-
Measurement Speed to 15/second
-
Graphical LCD Display
-
Four Terminal Kelvin Connection
-
Automatic Zeroing
-
Automatic Hi/Lo Comparator Limits
-
Pass/Fail Sorting (8 Bins)
-
Voltage Limiting for Dry Contact Testing
-
Signal Reverse & Pulsed Cur Modes
-
Keypad Lockout
-
Programmable Delay Times
-
RS-232 Interface Standard
-
IEEE & Handler Interfaces, Optional
-
Temperature Compensation Interface, Optional
