Rigol
Rigol DG4062
60 MHz Arbitrary Waveform Generator
60 MHz Frecuencia máxima de salida
2 canales independientes Número de canales
1 µHz Resolución de frecuencia
16 kpts (estándar), hasta 512 kpts (opcional) Profundidad de memoria de forma de onda
14 bits Resolución vertical (DAC)
| Atributo | Valor |
|---|---|
| Frecuencia máxima de salida | 60 MHz |
| Número de canales | 2 canales independientes |
| Resolución de frecuencia | 1 µHz |
| Profundidad de memoria de forma de onda | 16 kpts (estándar), hasta 512 kpts (opcional) |
| Resolución vertical (DAC) | 14 bits |
| Amplitud de salida | 1 mVpp a 20 Vpp (en carga de 50 Ω) |
| Impedancia de salida | 50 Ω |
| Tipos de modulación | AM, FM, PM, ASK, FSK, PSK, PWM y modulación de barrido |
| Interfaz de comunicación | USB Host, USB Device (USBTMC), LAN (LXI Core 2011) |
| Pantalla | Pantalla TFT LCD a color de 4,3 pulgadas |
| Model | DG4062 |
|---|
As Rigol's newest waveform generator, the DG4000 series is part of a new family of fast, easy-to-use, ultra-modern testing instruments. DG4000 is a multifunctional generator that helps accomplish a range of testing by combining many functions into one instrument. Functions include Function Generation, Arbitrary Waveform Generation, Pulse Generation, Harmonic Generation, and Analog/Digital Modulation and Counting. The DG4000 utilizes Direct Digital Synthesizer (DDS) technology, which delivers stable, precise, low distortion signals. The sleek new design features a high resolution 7? display screen, while user-friendly interface design and panel layout improves efficiency.
