Sorensen SGI60-333
| Atributo | Valor |
|---|---|
| Tensión de salida máxima | 60 V |
| Corriente de salida máxima | 333 A |
| Potencia máxima | 20.000 W (20 kW) |
| Tipo de salida | Corriente continua (CC) |
| Regulación de tensión en línea | 0,02% + 2 mV |
| Regulación de corriente en línea | 0,02% + 2 mA |
| Tensión de entrada | 208/240 V CA trifásico, 50/60 Hz |
| Interfaces de control | Analógica y RS-232/RS-485 (opcional GPIB) |
| Temperatura de operación | 0 °C a 50 °C |
| Dimensiones (An x Al x Pr) | 483 mm x 133 mm x 648 mm (3U) |
Sorensen SGI60-333 Options:
- SGI60-333 - C - Input Voltage 187 / 242VAC, 3 Phase
- SGI60-333 - D - Input Voltage 342 / 440VAC, 3 Phase
- SGI60-333 - E - Input Voltage 396 / 528VAC, 3 Phase
- SGI60-333 - 0A - No Remote Control Option
- SGI60-333 - 1A - IEEE-488.2 + RS-232C
- SGI60-333 - 1C - Ethernet + RS-232C
- SGI60-333 - 1D - Isolated Analog Control
- SGI60-333 - 2A - Combined Options 1A+1D
- SGI60-333 - 2G - Combined Options 1C+1D
- SGI60-333 - AA - No Process Option
- SGI60-333 - AB - Certificate of Calibration to ANSI / NCSL Z540-1 (includes Test Data)
- SGI60-333 - AJ - Front panel dust filter - factory installed - 3U unit only
- SGI60-333 - CV - 400Hz AC input @ 208 VAC (does not carry CE, CSA or UL marks) (6U only) STD on 3U
- SGI60-333 - PF - Passive power factor correction to 0.9 (Only applicable to 40V, 60V to 800V. Included in 10V-30V, 50V and 1000V.)
- SGI60-333 - R - RoHS Compliant Version
| Model | SGI60-333 |
|---|
SORENSEN SGI60-333 DC Power Supply
The Sorensen SGI60-333 DC power supply is designed for exceptional load transient response, low noise and the highest power density in the industry. It combines onboard intelligent controls with the outstanding power electronics common to all SG family supplies. These controls enable sophisticated sequencing, constant power mode and save/recall of instrument settings. Looping of sequences makes the SGI60-333 ideal for repetitive testing.
With a full 20 kW available in a 6U package the Sorensen SGI60-333 leads the industry in power density. The power density is enhanced by a stylish front air intake allowing supplies to be stacked without any required clearance between units. An impressive vacuum fluorescent graphical display in eight languages, context sensitive €œsoft " keys and front panel keyboard simplify programming of the SGI60-333. Up to 5 units may be paralleled for additional cur within the power supply single-unit specifications, with exception of the DC output cur set accuracy. Additional paralleled units will add 0.3% inaccuracy per unit.
Specifications for the SORENSEN SGI60-333 DC Power Supply Include:
| Voltage | 600V |
| Cur | 333A |
| Total Power | 20kW |
| Ripple & Noise (RMS) | 100 mV |
