Rohde & Schwarz NRP110TWGN
| Attribut | Valeur |
|---|---|
| Plage de fréquences | DC à 110 GHz |
| Plage de puissance mesurée | -35 dBm à +20 dBm |
| Type de connecteur | 1,0 mm (W) |
| Incertitude de mesure | ± 0,9 % (typique) |
| Interface de communication | USB 2.0 |
| Temps de mesure | Jusqu'à 1 500 mesures par seconde |
| Type de détection | Capteur de puissance thermique (à large bande) |
| Impédance | 50 Ω |
| Plage de température de fonctionnement | 0 °C à +55 °C |
| Compatibilité | Compatible avec les bases de mesure de puissance R&S NRP2 et R&S NRPxx |
| Model | NRP110TWGN |
|---|
Rohde & Schwarz NRP110TWGN Thermal Power Sensor
The Rohde & Schwarz NRP110TWGN Thermal Power Sensor is especially used for complex measurement tasks where highest accuracy counts. This power sensor can tolerate any type of modulation. To improve measurement accuracy, the hardware of the Rohde & Schwarz NRP110TWGN thermal power sensors is designed to reduce measurement noise to a minimum and to make the sensor immune to thermal environmental effects. To achieve stable measurement results, the temperature in the thermal test cell is correspond to the applied power. When the power is increased, the sophisticated measurement cell of the Rohde & Schwarz NRP110TWGN thermal power sensors quickly attains a stable temperature. When the power level is decreased, the excess heat is dissipated extremely quickly.
The Rohde & Schwarz NRP110TWGN Thermal Power Sensor features internal calibration tests which grants reliable and stable measurements. It unifies excellent impedance matching with a sophisticated connector concept. The sensor can be easily screw-connected to the signal source to be measured contributing high measurement accuracy. The Rohde & Schwarz NRP110TWGN Thermal Power Sensor is available as USB sensors and can be additionally controlled via LAN. This makes the Rohde & Schwarz NRP110TWGN portfolio ideal for use in production, R&D and calibration labs as well as for installation and maintenance tasks. The Rohde & Schwarz NRP110TWGN Thermal Power Sensor is ideal for use in production, R&D and calibration labs as well as for installation and maintenance tasks.
Specifications for the Rohde & Schwarz NRP110TWGN Thermal Power Sensor Include:
| Frequency range | 75 GHz to 110 GHz |
| Level range | -35 dBm to +20 dBm |
| Connector type | WR10 |
| Noise (typ.) | 20 nW |
