Keithley 2268-80-10
| Attribute | Value |
|---|---|
| Output Voltage | 0 – 80 V |
| Output Current | 0 – 10 A |
| Output Power | 800 W |
| Number of Outputs | Single Output |
| Line Regulation (Voltage) | ≤ 0.01% + 3 mV |
| Load Regulation (Voltage) | ≤ 0.01% + 3 mV |
| Ripple and Noise (RMS) | ≤ 3 mV RMS |
| Interface | GPIB, RS-232, USB |
| AC Input Voltage | 100 – 240 VAC, 47 – 63 Hz |
| Operating Temperature | 0°C to 40°C |
Keithley 2268-80-10 Options:
- 2268-80-10 - EW - 1 additional year of factory warranty
- 2268-80-10 - 5Y-EW - 2 additional years of factory warranty beyond the standard 3-year warranty
- C/2268-80-10 - 3Y-STD - 3 calibrations within 3 years of purchase
- C/2268-80-10 - 3Y-DATA - 3 (ANSI-Z540-1 compliant) calibrations within 3 years of purchase
- C/2268-80-10 - 5Y-STD - 5 calibrations within 5 years of purchase
- C/2268-80-10 - 5Y-DATA - 5 (ANSI-Z540-1 compliant) calibrations within 5 years of purchase
| Model | 2268-80-10 |
|---|
The Keithley 2268-80-10 offers 850W output at 80V and 10.5A, with auxiliary 15V and 5V outputs for control tasks. It features RS-485 connectivity for linking up to 30 units, constant voltage/current/power control, foldback with delay, and safety protections like over-voltage, over-current, and over-temperature shutdowns. Its analog controls support master-slave setups and configurations for bipolar outputs or higher power systems.
Ideal for production, environmental, and life testing, the 2268-80-10 simplifies power distribution across multiple units while minimizing system complexity and risk.
Testwall can supply the used Keithley 2268-80-10, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keithley 2268-80-10.
