Keysight (Agilent)
Keysight (Agilent) 11716C
Attenuator Connector Kit
DC to 26.5 GHz Frequency Range
Switch/Attenuator Driver Function
Dual Channel (2 independent channels) Number of Channels
0 V to -15 V (adjustable) Output Voltage
Up to 120 mA per channel Output Current
| Attribute | Value |
|---|---|
| Frequency Range | DC to 26.5 GHz |
| Function | Switch/Attenuator Driver |
| Number of Channels | Dual Channel (2 independent channels) |
| Output Voltage | 0 V to -15 V (adjustable) |
| Output Current | Up to 120 mA per channel |
| Input Control Interface | BNC connectors for TTL/CMOS compatible control signals |
| Power Supply Requirement | +15 V and -15 V DC (supplied via rear panel connector) |
| Connector Type | BNC (input), SMA (output drive connectors) |
| Compatible Devices | Designed for use with Keysight/Agilent switches and step attenuators |
| Operating Temperature | 0°C to 55°C |
| Model | 11716C |
|---|
The HP Agilent 11716C quickly and conveniently connects 1 dB step and 10 dB step attenuators together to achieve greater dynamic range with 1 dB steps. The Agilent 11716C can be utilized to connect any of the two Agilent 8494/95/96 attenuators in series.
