Keysight (Agilent) DSO80804B 4 Ch 8 GHz Digital Oscilloscope
4 Ch 8 GHz Digital Oscilloscope
8 GHz Bandwidth
4 Number of Channels
40 GSa/s Maximum Sample Rate
Up to 2 Gpts (with memory option) Memory Depth
8-bit (up to 12-bit in high-resolution mode) Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 8 GHz |
| Number of Channels | 4 |
| Maximum Sample Rate | 40 GSa/s |
| Memory Depth | Up to 2 Gpts (with memory option) |
| Vertical Resolution | 8-bit (up to 12-bit in high-resolution mode) |
| Rise Time | 50 ps |
| Timebase Range | 5 ps/div to 20 s/div |
| Input Impedance | 50 Ω or 1 MΩ |
| Display | 15-inch XGA color display (1024 x 768) |
| Trigger Types | Edge, Glitch, Pattern, TV, Delay, Violation, Transition, State, Setup/Hold, Serial |
Keysight Technologies DSO80804B 4 Ch 8 GHz Digital Oscilloscope Options:
- DSO80804B - 001 - 2-M (2 channels), 1-M (4 channels) memory upgrade; 64 M (2 channels at 4 GSa/s) or 32 M (4 channels ≤ 2 GSa/s)
- DSO80804B - 002 - EZJIT jitter analysis software (installed at the factory)
- DSO80804B - 003 - High-speed serial data analysis/mask testing with clock recovery and 8b/10b decoding (installed at the factory)
- DSO80804B - 004 - EZJIT Plus jitter analysis software (installed at the factory)
- DSO80804B - 005 - Noise reduction and bandwidth control option (installed at the factory)
- DSO80804B - 006 - My Infiniium integration package (installed at the factory)
- DSO80804B - 007 - Low-speed serial data analysis for I2C/SPI (installed at the factory)
- DSO80804B - 008 - Low-speed serial data analysis for CAN (installed at the factory)
- DSO80804B - 009 - InfiniiScan event identification software (installed at the factory)
- DSO80804B - 010 - Infiniium user defined function application software (installed at the factory)
- DSO80804B - 017 - ≥ 40 Gb removable hard disk drive; replaces internal hard disk with a removable hard disk
- DSO80804B - 1CM - Rack-mount kit (E2609B)
- DSO80804B - A6J - ANSI Z540-compliant calibration
| Model | DSO80804B |
|---|
The Keysight (Agilent) DSO80804B provides 8 GHz bandwidth (upgradable to 13 GHz), 4 channels, up to 40 GSa/s sampling, and memory options from 512 kpts to 64 Mpts.
Offers low noise floor, ultra-low jitter, advanced InfiniiMax II probing, and full jitter and customization analysis toolsets.
Testwall can supply the used Keysight (Agilent) DSO80804B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) DSO80804B.
