Keysight (Agilent) J7201B
| Attribute | Value |
|---|---|
| Attenuation Range | 0 to 110 dB |
| Frequency Range | DC to 4 GHz |
| Attenuation Step Size | 1 dB |
| Impedance | 50 Ohm |
| Connector Type | SMA (f) to SMA (f) |
| Maximum Input Power | 1 W (30 dBm) |
| SWR (Voltage Standing Wave Ratio) | 1.5:1 maximum |
| Switching Speed | Less than 10 ms |
| Control Interface | USB |
| Operating Temperature | 0°C to 55°C |
| Model | J7201B |
|---|
The Keysight (Agilent) J7201B is a high-performance Attenuation Control Unit operating from DC to 18 GHz, offering a wide attenuation range from 0 to 121 dB with selectable steps of 1 dB, 5 dB, and 10 dB. It features SMA/Type-N (f) connectors and insertion loss values of 2.5 dB below 6 GHz and 5.0 dB above 6 GHz, with return loss of 14 dB and 10 dB respectively.
This unit is ideal for precision RF and microwave testing applications requiring accurate signal control over broad frequency bands.
Testwall can supply the used Keysight (Agilent) J7201B, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) J7201B.
