Keysight (Agilent)
Keysight (Agilent) N5531S
Measuring Receiver System (configurable)
100 Hz to 26.5 GHz Frequency Range
Measuring Receiver System for Signal Analyzers Measurement System
Keysight PSA Series Spectrum Analyzers (E4440A, E4443A, E4445A, E4446A, E4448A) Compatible Instruments
N5530A Measuring Receiver Software, N5532A Sensor Module, Cables, and Accessories Included Components
Up to 90 dB Dynamic Range
| Attribute | Value |
|---|---|
| Frequency Range | 100 Hz to 26.5 GHz |
| Measurement System | Measuring Receiver System for Signal Analyzers |
| Compatible Instruments | Keysight PSA Series Spectrum Analyzers (E4440A, E4443A, E4445A, E4446A, E4448A) |
| Included Components | N5530A Measuring Receiver Software, N5532A Sensor Module, Cables, and Accessories |
| Dynamic Range | Up to 90 dB |
| Power Measurement Accuracy | ±0.2 dB typical |
| Input Connector Type | 2.4 mm (f) RF Input |
| Measurement Functions | Absolute Power, Gain, Noise Figure, Insertion Loss, and Frequency Response |
| Interface | GPIB and USB |
| Operating Temperature Range | 0°C to 55°C |
Keysight (Agilent) N5531S Measuring Receiver System (configurable) Options:
- N5531S - 107 - E444Xa Audio Input 100 Ko (Needs 233)
- N5531S - 110 - E444Xa Rf/ 碌W Internal Preamplifier (Not With 1Ds)
- N5531S - 123 - E444Xa Switchable Preselector Bypass
- N5531S - 1DS - E444Xa Rf Internal Preamplifier (Not With 110)
- N5531S - 233 - E444Xa Built-In Measuring Receiver Personality And Pc Software
- N5531S - 23A - Am/Fm/Pm Triggering (Std With 233)
- N5531S - 23B - Ccitt Filter (Std With 233)
- N5531S - E4440A - 26.5GHZ Psa Analyzer
- N5531S - E4443A - 6.7GHZ Psa Analyzer
- N5531S - E4445A - 13.2GHZ Psa Analyzer
- N5531S - E4446A - 44GHZ Psa Analyzer
- N5531S - E4447A - 42.98GHZ Psa Analyzer
- N5531S - E4448A - 50GHZ Psa Analyzer
- N5531S - N1911A - P-Series Single Channel Power Meter
- N5531S - N1912A - P-Series Dual Channel Power Meter
- N5531S - N5532A-019 - Adaptor To N191Xa Power Meter
- N5531S - N5532A-504 - 100 KHZ To 4.2 GHZ, Type N(M) Input Connector
- N5531S - N5532A-518 - 10 MHZ To 18 GHZ, Type N(M) Input Connector
- N5531S - N5532A-526 - 30 MHZ To 26.5 GHZ, Apc 3.5 (M) Input Connector
- N5531S - N5532A-550 - 30 MHZ To 50 GHZ, 2.4 Mm (M) Input Connector
| Model | N5531S |
|---|
Keysight (Agilent) N5531S Measuring Receiver System (configurable) Description: The Keysight (Agilent) N5531S measuring receiver system is comprised of a PSA spectrum analyzer with Option 233, a P-Series power meter, and an N5532A sensor module for metrology and calibration applications. To achieve the optimal measurement results as specified, the best metrology practice must be applied and the required instrument conditions must be met. PSA is the core component instrument of the N5531S measuring receiver. The PSA instrument conditions included in the PSA specification guide must be met to meet the N5531S specifications.
