Rohde & Schwarz ESVP
| Attribute | Value |
|---|---|
| Frequency Range | 20 Hz – 1000 MHz |
| Measurement Functions | EMI test receiver for conducted and radiated interference measurements |
| Detector Types | Peak, Quasi-Peak, Average, RMS |
| IF Bandwidths | 200 Hz, 9 kHz, 120 kHz, 1 MHz (CISPR-compliant bandwidths) |
| Dynamic Range | Up to 100 dB |
| Input Impedance | 50 Ω |
| RF Input Level (Max) | +13 dBm continuous |
| Compliance Standards | CISPR 16-1, VDE 0876, MIL-STD-461 |
| Display | Built-in CRT display with scan and bargraph presentation |
| Interface / Connectivity | IEEE-488 (GPIB) interface for automated test system integration |
| Model | ESVP |
|---|
The Rohde & Schwarz ESVP is a highly reliable receiver operating in the 20MHz to 1300MHz range, with a measurement capability from -20 to +127 dBµV. Designed for flexibility, it supports external battery power from 22 to 32V, making it ideal for portable and remote testing applications.
Used primarily in electromagnetic compatibility (EMC) testing and spectrum analysis, this unit offers accurate signal reception with a wide dynamic range. Its robust construction ensures consistent results across demanding environments.
Testwall can supply the used Rohde & Schwarz ESVP, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz ESVP.
