Keysight (Agilent)
Keysight (Agilent) N9961B
44GHz Fieldfox Handheld Signal Analyzer
100 kHz to 32 GHz Frequency Range
7-inch color TFT LCD touchscreen Display
Up to 110 dB Dynamic Range
-163 dBm/Hz (with preamplifier) Displayed Average Noise Level (DANL)
-98 dBc/Hz at 1 GHz, 10 kHz offset Phase Noise
| Attribute | Value |
|---|---|
| Frequency Range | 100 kHz to 32 GHz |
| Display | 7-inch color TFT LCD touchscreen |
| Dynamic Range | Up to 110 dB |
| Displayed Average Noise Level (DANL) | -163 dBm/Hz (with preamplifier) |
| Phase Noise | -98 dBc/Hz at 1 GHz, 10 kHz offset |
| Amplitude Accuracy | ±0.5 dB |
| Battery Life | Approximately 4 hours with standard battery pack |
| Weight | Approximately 4.76 kg (10.5 lbs) |
| Operating Temperature Range | -10°C to +55°C |
| Connectivity/Interfaces | USB, LAN (Ethernet), GPS receiver support |
| Model | N9961B |
|---|
Keysight (Agilent) N9961B 44GHz Fieldfox Handheld Signal Analyzer Description: Frequency Range: 9 kHz to 44 GHz Base model includes Signal Analyzer as standard Options to add Reflection measurements, Real-time spectrum analyzer, I/Q analysis etc. Lightweight, portable & battery powered Keysight (Agilent) N9961B 44GHz Fieldfox Handheld Signal Analyzer
