Keysight (Agilent) 54122A
| Attribute | Value |
|---|---|
| Bandwidth | 12.4 GHz |
| Number of Channels | 4 Channels |
| Sample Rate | Up to 1 GSa/s |
| Rise Time | 28.3 ps |
| Timebase Range | 50 ps/div to 200 ms/div |
| Vertical Sensitivity | 1 mV/div to 1 V/div |
| Input Impedance | 50 Ohms |
| Memory Depth | 4 Kpoints per channel |
| Display Type | Built-in CRT Display |
| Interface/Connectivity | GPIB (IEEE-488) |
| Model | 54122A |
|---|
The Keysight (Agilent) 54122A is a 12.4 GHz 4-channel test set, engineered for high-frequency applications with precision performance. It features a proprietary module interface, 50 Ohm input impedance, and a bandwidth of 12.4 GHz. With vertical sensitivity ranging from 1 mV/div to 80 V/div, and a rise time of 28.2 ps, it ensures accurate signal capture. The 54122A supports both Free Run and Triggered Modes, high-frequency rejection, and includes internal attenuation for enhanced measurement control.
Ideal for advanced RF testing, the 54122A includes multiple adapters, cables, and accessories for versatile connectivity. It delivers exceptional timing accuracy with a minimum base time of 0.01 ns/div and trigger sensitivity down to 40 mV.
Testwall can supply the used Keysight (Agilent) 54122A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 54122A.
