Keysight (Agilent) 54622D
2 + 16 Channel 100MHz 200MS/s Digital Storage Oscilloscope
2 analog channels + 16 digital channels Number of Channels
100 MHz Bandwidth
200 MSa/s (analog), 400 MSa/s (digital) Sample Rate
2 Mpts per channel Memory Depth
8 bits Vertical Resolution
| Attribute | Value |
|---|---|
| Number of Channels | 2 analog channels + 16 digital channels |
| Bandwidth | 100 MHz |
| Sample Rate | 200 MSa/s (analog), 400 MSa/s (digital) |
| Memory Depth | 2 Mpts per channel |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 5 V/div |
| Time Base Range | 5 ns/div to 50 s/div |
| Display | 6.5-inch color LCD display |
| Input Impedance | 1 MΩ ± 1% in parallel with 13 pF ± 2 pF |
| Interface | GPIB, RS-232, parallel printer port |
Keysight Technologies 54622D Options:
- 54622D - 003 - Shielding Option for use in severe environments or with sensitive devices under test – shields both ways (in and out): RS-03 Magnetic interface shielding added to CRT, and RE-02 display shield added to CRT to reduce radiated interference
- 54622D - 1CM - Rackmount kit (same as 1186A)
- 54622D - A6J - ANSI/NSCL Z540 calibration with test data (replaces 1BP)
- 54622D - ABA - Manual Option: English
- 54622D - ABJ - Manual Option: Japanese
- 54622D - AB2 - Manual Option: Simplified Chinese
- 54622D - R-50C-011-3 - 3-years of return-to-Agilent inclusive calibration service
- 54622D - R-50C-013-3 - 3-years of return-to-Agilent inclusive plus calibration service
- 54622D - R-50C-011-5 - 5-years of return-to-Agilent inclusive calibration service
- 54622D - R-50C-013-5 - 5-years of return-to-Agilent inclusive plus calibration service
- 54622D - R-51B-001-3C - 1-year return-to-Agilent warranty, extended to 3-years
- 54622D - R-51B-001-5C - 1-year return-to-Agilent warranty, extended to 5-years
| Model | 54622D |
|---|
The Keysight (Agilent) 54622D is a 2+16 channel mixed signal oscilloscope combining 100 MHz bandwidth and 2 GSa/s sampling rate across two analog channels with 16 digital logic channels. This hybrid design enables simultaneous visibility of analog waveforms and digital signal timing across up to 18 channels—ideal for debugging embedded systems, microcontrollers, and mixed-signal circuits. The MSO integrates scope-grade signal fidelity with logic analyzer functionality for precise analysis of complex signal interactions.
Advanced triggering, protocol verification, and productivity options (including shielding, rackmount, and assistance modules) enhance usability and test coverage.
Testwall can supply the used Keysight (Agilent) 54622D, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) 54622D.
