Keysight (Agilent) DSO5054A
| Attribute | Value |
|---|---|
| Bandwidth | 500 MHz |
| Number of Channels | 4 |
| Sample Rate | 2 GSa/s (on 2 channels), 1 GSa/s (on 4 channels) |
| Memory Depth | 4 Mpts (standard), 8 Mpts (optional) |
| Vertical Resolution | 8 bits |
| Vertical Sensitivity | 1 mV/div to 5 V/div |
| Timebase Range | 2 ns/div to 50 s/div |
| Display | 7-inch QVGA (320 x 240) color LCD |
| Input Impedance | 1 MΩ ± 1% in parallel with 13 pF ± 3 pF |
| Waveform Update Rate | Up to 1,000 waveforms per second |
| Model | DSO5054A |
|---|
The Keysight (Agilent) DSO5054A is a 500 MHz, 4-channel oscilloscope with a 4 GSa/s sample rate, offering deep 8 Mpts memory and real-time update rates of up to 100,000 waveforms/sec. It features advanced protocol decoding and a sharp XGA display.
Ideal for high-speed signal analysis, the DSO5054A supports triggering on multiple protocols like I2C, SPI, CAN, LIN, and UART, with flexible connectivity including USB, LAN, and GPIB.
Testwall can supply the used Keysight (Agilent) DSO5054A Oscilloscope, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) DSO5054A Oscilloscope.
