Keysight (Agilent)
Keysight (Agilent) DSOS104A
Oscilloscope - Infiniium S Series 1 GHz 4 channel
1 GHz Bandwidth
4 Analog Channels Number of Channels
20 GSa/s Sample Rate
800 Mpts (standard), up to 2 Gpts (optional) Memory Depth
8-bit (up to 10-bit in high-resolution mode) Vertical Resolution
| Attribute | Value |
|---|---|
| Bandwidth | 1 GHz |
| Number of Channels | 4 Analog Channels |
| Sample Rate | 20 GSa/s |
| Memory Depth | 800 Mpts (standard), up to 2 Gpts (optional) |
| Vertical Resolution | 8-bit (up to 10-bit in high-resolution mode) |
| Display | 15.6-inch capacitive touch screen, 1920 x 1080 resolution |
| Waveform Update Rate | 1,000,000 waveforms/second |
| Timebase Range | 5 ps/div to 20 s/div |
| Connectivity | USB, LAN (LXI), GPIB (optional), DisplayPort |
| Operating System | Windows 10 (64-bit) |
Keysight Technologies DSOS104A Options:
- DSOS104A - DSOS000-200 - Memory upgrade: 200 Mpts x 4 channels, 400 Mpts x 2 channels (factory-installed)
- DSOS104A - DSOS000-400 - Memory upgrade: 400 Mpts x 4 channels, 800 Mpts x 2 channels (factory-installed)
- DSOS104A - DSOS000-821 - Precision BNC (M) to SMA (F) adapters (qty 2)
- DSOS104A - DSOS000-1A7 - 170225 compliant calibration
- DSOS104A - DSOS000-AMG - 17025 compliant calibration with accreditation
- DSOS104A - DSOS000-A6J - ANSI Z540 compliant calibration
- DSOS104A - DSOS8GBW - Bandwidth upgrade to 8 GHz
- DSOS104A - DSOS6GBW - Bandwidth upgrade to 6 GHz
- DSOS104A - DSOS4GBW - Bandwidth upgrade to 4 GHz
- DSOS104A - DSOS2G5BW - Bandwidth upgrade to 2.5 GHz
- DSOS104A - DSOS2GBW - Bandwidth upgrade to 2 GHz
- DSOS104A - N2113A-100 - Memory upgrade: 50 Mpts/100 Mpts to 100 Mpts/200 Mpts (post-sale)
- DSOS104A - N2113A-200 - Memory upgrade: 100 Mpts/200 Mpts to 200 Mpts/400 Mpts (post-sale)
- DSOS104A - N2113A-400 - Memory upgrade: 200 Mpts/400 Mpts to 400 Mpts/800 Mpts (post-sale)
- DSOS104A - N2901E - MSO upgrade kit (upgrades DSO to MSO in less than 1 minute)
- DSOS104A - N2902B - S-Series rackmount kit (8U high)
- DSOS104A - N2746S - Additional SSD with Windows 7
- DSOS104A - N4865A - GPIB to LAN adapter
- DSOS104A - DSOS000-DSA - DSA bundle with EZJIT Complete and SDA (new purchase only)
| Model | DSOS104A |
|---|
The Keysight DSOS104A is a 1 GHz oscilloscope with 4 analog channels, 10-bit ADC, and 20 GSa/s sample rate, with 100 Mpts memory/channel.
Includes ENOB of 8.1 bits, multi-touch 15” screen, SSD, and bundled analysis and protocol software for compliance testing.
Testwall can supply the used Keysight Technologies DSOS104A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight Technologies DSOS104A.
