Keysight (Agilent) DSOX3024A
| Attribute | Value |
|---|---|
| Number of Channels | 4 Analog Channels |
| Bandwidth | 200 MHz |
| Sample Rate | 4 GSa/s |
| Memory Depth | 4 Mpts (standard), up to 8 Mpts with upgrade |
| Display | 8.5-inch WVGA (800 x 480) color display |
| Waveform Update Rate | Up to 1,000,000 waveforms per second |
| Vertical Resolution | 8-bit (up to 12-bit with high resolution mode) |
| Vertical Sensitivity | 1 mV/div to 10 V/div |
| Time Base Range | 2 ns/div to 50 s/div |
| Connectivity | USB Host, USB Device, LAN (LXI Core 2011), GPIB (optional) |
Keysight (Agilent) DSOX3024A Options:
- DSOX3024A - DSOX3MEMUP - Memory upgrade (standard 2 Mpts to 4 Mpts)
- DSOX3024A - DSOX3SGM - Segmented memory
- DSOX3024A - DSOX3MSO - MSO upgrade: add 16 digital timing channels (for 500 MHz and below models)
- DSOX3024A - DSOX3WAVEGEN - WaveGen built-in 20 MHz function/arbitrary waveform generator
- DSOXDVM - DSOXDVM - Integrated 3-digit digital voltmeter (DVM)
- DSOX3024A - DSOX3MASK - Mask/limit testing
- DSOX3024A - DSOX3ADVMATH - Advanced waveform math
- DSOX3024A - DSOX3VID - Enhanced video/TV triggering and analysis
- DSOX3024A - DSOX3EMBD - Embedded serial triggering and analysis (I²C, SPI)
- DSOX3024A - DSOX3COMP - Computer serial triggering and analysis (RS232/422/485/UART)
- DSOX3024A - DSOX3AUDIO - Audio serial triggering and analysis (I²S)
- DSOX3024A - DSOX3AUTO - Automotive serial triggering and analysis (CAN, LIN)
- DSOX3024A - DSOX3FLEX - FlexRay serial triggering and analysis
- DSOX3024A - DSOX3AERO - Aerospace serial triggering and analysis (MIL-STD 1553, ARINC 429)
- DSOX3024A - DSOX3PWR - Power measurements and analysis
- DSOX3024A - DSOXEDK - Educator's oscilloscope training kit
- DSOX3024A - DSOX3BW24 - Bandwidth upgrade: 100 MHz to 200 MHz, 4 ch, License only
- DSOX3024A - DSOX3BW34 - Bandwidth upgrade: 200 MHz to 350 MHz, 4 ch, Service center
- DSOX3024A - DSOXLAN - LAN/VGA connection module
- DSOX3024A - DSOXGPIB - GPIB connection module
| Model | DSOX3024A |
|---|
The Keysight (Agilent) DSOX3024A is a powerful digital storage and mixed signal oscilloscope, offering bandwidths from 100 MHz to 1 GHz, optional 16 digital MSO channels, built-in 20 MHz function generator, 3-digit voltmeter, and a 5-digit counter for rapid signal characterization.
Ideal for debugging, design, and serial bus analysis, it supports decoding of CAN, LIN, I²C, SPI, RS232, and offers full upgradability to protect your investment.
Testwall can supply the used Keysight (Agilent) DSOX3024A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) DSOX3024A.
