Keysight (Agilent) E5070A
| Attribute | Value |
|---|---|
| Frequency Range | 300 kHz to 3 GHz |
| Number of Ports | 2 or 4 ports |
| Dynamic Range | Up to 120 dB |
| Output Power Range | -55 dBm to +10 dBm |
| Measurement Parameters | S-parameters, impedance, admittance, group delay, phase |
| Display | 10.4-inch color LCD touchscreen |
| Number of Data Points | Up to 16,001 points per trace |
| Trace Noise Floor | 0.001 dB rms (at 10 Hz IF bandwidth) |
| Interface / Connectivity | GPIB, LAN (10Base-T/100Base-TX), USB |
| Power Requirements | 100–240 V AC, 50/60 Hz, 350 VA maximum |
Keysight Technologies E5070A Options:
- E5070B - 214 - 2-port configuration
- E5070B - 314 - 3-port configuration
- E5070B - 414 - 4-port configuration
- E5071B - 214 - 2-port configuration
- E5071B - 314 - 3-port configuration
- E5071B - 414 - 4-port configuration
- E5070B - 008 - Frequency-offset measurement capability
- E5071B - 008 - Frequency-offset measurement capability
- E5070B - 010 - Time domain analysis
- E5071B - 010 - Time domain analysis
- E5070B - 016 - Touch screen interface
- E5071B - 016 - Touch screen interface
- E5070B - UNQ - Standard frequency reference (±5 ppm, 5°C to 40°C)
- E5071B - UNQ - Standard frequency reference (±5 ppm, 5°C to 40°C)
- E5070B - 1E5 - High-stability frequency reference (±0.05 ppm, 23°C ±5°C)
- E5071B - 1E5 - High-stability frequency reference (±0.05 ppm, 23°C ±5°C)
- E5091A - 009 - 9-port multiport test set with Type-N connectors
- E5091A - 016 - 25-port multiport test set with SMA connectors
| Model | E5070A |
|---|
The Keysight (Agilent) E5070A RF Network Analyzer operates from 300 kHz to 3 GHz and supports 2-, 3-, and 4-port testing. It provides 125 dB dynamic range, 9.6 µs/point sweep speed, and 0.001 dB rms trace noise for precise analysis of multi-port and balanced devices.
It features built-in time-domain transform with gating, mixed-mode S-parameters, and frequency-offset mode. Integrated de-embedding tools and VBA scripting offer advanced customization and automation.
Testwall can supply the used Keysight (Agilent) E5070A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E5070A.
