Keysight (Agilent) E8257D-550
| Attribute | Value |
|---|---|
| Frequency Range | 250 kHz to 50 GHz |
| Output Power Range | +20 dBm to -20 dBm (typical, frequency dependent) |
| Phase Noise | -105 dBc/Hz at 10 kHz offset (at 10 GHz carrier) |
| Frequency Resolution | 0.001 Hz |
| Modulation Types | AM, FM, Phase Modulation, Pulse Modulation |
| Output Connector | 2.4 mm (f) RF output connector |
| Spectral Purity (Harmonics) | Less than -55 dBc (typical) |
| Frequency Switching Speed | Less than 5 ms (typical) |
| Power Supply | 100–240 VAC, 50/60 Hz, automatic selection |
| Interface/Connectivity | GPIB, LAN (LXI), USB |
| Model | E8257D-550 |
|---|
The Keysight (Agilent) E8257D-550 delivers a frequency range from 250 kHz to 50 GHz, providing robust performance for advanced wideband testing without external amplification. It offers +30 dBm output power (with option) and superior phase noise of ~–126 dBc/Hz at 10 GHz, 10 kHz offset, supporting AM, FM, PM, and pulse modulation for precision testing.
Designed for radar, EMC, and high-bandwidth systems, this signal generator excels in applications demanding low-phase-noise signals and high output power, especially in next-gen RF environments.
Testwall can supply the used Keysight (Agilent) E8257D-550, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) E8257D-550.
