Keysight (Agilent) N1022A
| Attribute | Value |
|---|---|
| Product Family | N1022A TDR/TDT Cable and Connector Test Set |
| Frequency Range | DC to 50 GHz |
| Connector Type | 2.4 mm (female) |
| Number of Ports | 4-port test set |
| Compatible Instruments | Keysight 86100C/D Infiniium DCA-X Wide-Bandwidth Oscilloscope |
| Application | Time Domain Reflectometry (TDR) and Time Domain Transmission (TDT) measurements for cables and connectors |
| Rise Time | Less than 35 ps (typical) |
| Impedance | 50 Ohm |
| Operating Temperature | 0°C to 55°C |
| Interface | Compatible with Keysight 54754A TDR module for differential and single-ended measurements |
| Model | N1022A |
|---|
The Keysight (Agilent) N1022A probe adapter offers a high-integrity signal path and power interface for InfiniiMax active probes used with the 86100 Infiniium DCA series. It ensures seamless connectivity between probe and oscilloscope via a precision 3.5 mm instrumentation-grade connector. Designed for compatibility with 861XX, 8348X, and 5475X modules supporting up to 20 GHz bandwidth.
This adapter enables advanced waveform analysis with reliable signal fidelity, making it ideal for high-speed digital circuit evaluations.
Testwall can supply the used Keysight (Agilent) N1022A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N1022A.
