Keysight (Agilent) N1077A
| Attribute | Value |
|---|---|
| Product Family | N1077A Clock Recovery Instrument |
| Data Rate Range | 9.8 Gb/s to 11.3 Gb/s |
| Input Connector Type | SMA (Female) |
| Output Connector Type | SMA (Female) |
| Loop Bandwidth | 4 MHz (fixed) |
| Input Voltage (Differential) | 20 mV to 1000 mV peak-to-peak |
| Output Clock Amplitude | 500 mV peak-to-peak (typical, into 50 Ω) |
| Power Supply | +12 V DC, external power adapter included |
| Interface/Control | USB 2.0 for remote control and firmware updates |
| Operating Temperature | 0 °C to 40 °C (32 °F to 104 °F) |
Keysight (Agilent) N1077A Options:
- N1077A - 216 - Supported input rates: 50 MBd to 16 GBd
- N1077A - 232 - Supported input rates: 50 MBd to 32 GBd
- N1077A - SMS - Internal single-mode (9/125 µm) and multimode (50/125 µm) splitter
- N1077A - SXT - No splitter (external splitter supplied by user)
- N1077A - JSA - Jitter spectrum analysis and clock recovery emulation
| Model | N1077A |
|---|
The Keysight (Agilent) N1077A Optical/Electrical Clock Recovery offers standards-compliant clock recovery from 50 MBd to 32 GBd for both NRZ and PAM-4 signals in optical and electrical formats. It includes integrated splitter, bulk optics coupler (option SMS), and jitter spectrum analysis (option JSA).
This device is ideal for high-speed data testing with FlexPLL and PCIe PLL software applications, making it a reliable choice for detailed jitter diagnostics and compliant measurements.
Testwall can supply the used Keysight (Agilent) N1077A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N1077A.
