Keysight (Agilent) N5230A-245
4-port, 300KHz - 20GHz PNA-L Network Analyser
300 kHz to 13.5 GHz Frequency Range
4 Number of Ports
Up to 122 dB Dynamic Range
-85 dBm to +20 dBm Output Power Range
S-parameters, impedance, admittance, group delay, and mixed-mode parameters Measurement Parameters
| Attribute | Value |
|---|---|
| Frequency Range | 300 kHz to 13.5 GHz |
| Number of Ports | 4 |
| Dynamic Range | Up to 122 dB |
| Output Power Range | -85 dBm to +20 dBm |
| Measurement Parameters | S-parameters, impedance, admittance, group delay, and mixed-mode parameters |
| Interface/Connectivity | GPIB, USB, LAN (LXI compliant) |
| Display | 10.4-inch color LCD touchscreen |
| Test Port Connector Type | 3.5 mm (f) |
| Trace Noise (10 Hz IF Bandwidth) | 0.004 dB RMS |
| Operating Temperature Range | 0°C to 55°C (32°F to 131°F) |
Keysight Technologies N5230A-245 Options:
- N5230A-245 - 020 - Standard test set and standard power range, 300 kHz to 6 GHz
- N5230A-245 - 025 - Configurable test set and extended power range, 300 kHz to 6 GHz
- N5230A-245 - 120 - Standard test set and standard power range, 300 kHz to 13.5 GHz
- N5230A-245 - 125 - Configurable test set and extended power range, 300 kHz to 13.5 GHz
- N5230A-245 - 220 - Standard test set and standard power range, 10 MHz to 20 GHz
- N5230A-245 - 225 - Configurable test set and extended power range, 10 MHz to 20 GHz
- N5230A-245 - 420 - Standard test set and standard power range, 10 MHz to 40 GHz
- N5230A-245 - 425 - Configurable test set and extended power range, 10 MHz to 40 GHz
- N5230A-245 - 520 - Standard test set and standard power range, 10 MHz to 50 GHz
- N5230A-245 - 525 - Configurable test set and extended power range, 10 MHz to 50 GHz
- N5230A-245 - 080 - Fast sweep triggering option
- N5230A-245 - H08 - Special configuration option
- N5230A-245 - H11 - Special configuration option
| Model | N5230A-245 |
|---|
The Keysight (Agilent) N5230A-245 is an upgraded 2-port analyzer combining low-frequency extension with bias-tee and power-range capabilities. It supports a wide frequency span up to 50 GHz, tailored for comprehensive RF and DC measurements.
This modular system integrates low-frequency and bias technologies, high-power attenuators, and test flexibility, ideal for in-depth, multi-mode testing up to 50 GHz.
Testwall can supply the used Keysight (Agilent) N5230A-245, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N5230A-245.
