Keysight (Agilent)
Keysight (Agilent) N5245B-224
PNA B Series Microwave Analyzers
10 MHz to 50 GHz Frequency Range
4-Port Number of Ports
Up to 122 dB Dynamic Range
-90 dBm to +10 dBm Output Power Range
0.004 dB RMS at 10 Hz IF Bandwidth Trace Noise (Typical)
| Attribute | Value |
|---|---|
| Frequency Range | 10 MHz to 50 GHz |
| Number of Ports | 4-Port |
| Dynamic Range | Up to 122 dB |
| Output Power Range | -90 dBm to +10 dBm |
| Trace Noise (Typical) | 0.004 dB RMS at 10 Hz IF Bandwidth |
| Connector Type | 2.4 mm (f) Test Port Connectors |
| IF Bandwidth | 1 Hz to 15 MHz |
| Measurement Parameters | S-Parameters, Absolute Power, Impedance, Admittance, Group Delay |
| Option Type | Option 224 – Configurable Test Set, Direct Receiver Access |
| Operating Temperature Range | 0°C to 55°C (32°F to 131°F) |
| Model | N5245B-224 |
|---|
The Keysight (Agilent) N5245B-224 is a 2-port PNA-X analyzer with 10 MHz–50 GHz coverage, offering dual sources, intelligent 2.4 mm ports, and Option 224 for filtered/high-power mode control.
It supports pulsed and RF testing with up to 32,001 points for advanced signal analysis and wide power range performance.
Testwall can supply the used Keysight (Agilent) N5245B-224, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Keysight (Agilent) N5245B-224.
