Keysight (Agilent)
Keysight (Agilent) N5406A
FPGA Dynamic Probe
DC to 6 GHz Frequency Range
2-Port Number of Ports
Up to 130 dB Dynamic Range
-85 dBm to +20 dBm Output Power Range
Up to 40,000 points per second Measurement Speed
| Attribute | Value |
|---|---|
| Frequency Range | DC to 6 GHz |
| Number of Ports | 2-Port |
| Dynamic Range | Up to 130 dB |
| Output Power Range | -85 dBm to +20 dBm |
| Measurement Speed | Up to 40,000 points per second |
| Connector Type | Type-N (50 Ohm) |
| Trace Noise | 0.004 dB RMS |
| Number of Points per Sweep | 1 to 16,001 points |
| IF Bandwidth Range | 1 Hz to 15 MHz |
| Power Supply | 100–240 VAC, 50/60 Hz |
| Model | N5406A |
|---|
The Keysight (Agilent) N5406A dynamic probe is engineered for InfiniiVision MSOs and Xilinx FPGAs, allowing seamless real-time internal signal access without extra routing or additional I/O pins.
Ideal for developers debugging Xilinx FPGA designs, it facilitates efficient signal capture and analysis directly within the device environment.
Testwall can supply the used Keysight (Agilent) N5406A, fully tested.
With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality.
Please contact us directly if you need calibration or repair of the Keysight (Agilent) N5406A..
