Leader
Leader 5100
Component Waveform Monitor
1 MHz to 3 GHz Frequency Range
High-resolution LCD color display Display Type
50 Ω / 75 Ω selectable Input Impedance
Up to 80 dB Dynamic Range
-50 dBm to +30 dBm Reference Level Range
| Attribute | Value |
|---|---|
| Frequency Range | 1 MHz to 3 GHz |
| Display Type | High-resolution LCD color display |
| Input Impedance | 50 Ω / 75 Ω selectable |
| Dynamic Range | Up to 80 dB |
| Reference Level Range | -50 dBm to +30 dBm |
| Resolution Bandwidth | 1 kHz to 3 MHz |
| Sweep Time | 20 ms to 100 s |
| Power Supply | AC 100-240V, 50/60 Hz |
| Interface | USB, LAN (Ethernet), GPIB |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Model | 5100 |
|---|
Component Waveform Monitor
