Rohde & Schwarz UAF
Video Analyser
0.1 Hz to 25 kHz Frequency Range
Universal Active Filter Filter Type
Low-pass, High-pass, Band-pass, Band-stop (Notch), All-pass Filter Topologies
Up to 10th order Filter Order
10 kΩ Input Impedance
| Attribute | Value |
|---|---|
| Frequency Range | 0.1 Hz to 25 kHz |
| Filter Type | Universal Active Filter |
| Filter Topologies | Low-pass, High-pass, Band-pass, Band-stop (Notch), All-pass |
| Filter Order | Up to 10th order |
| Input Impedance | 10 kΩ |
| Output Impedance | Less than 1 Ω |
| Dynamic Range | Greater than 100 dB |
| Supply Voltage | ±15 V DC |
| Operating Temperature Range | 0°C to 50°C |
| Interface / Control | IEEE-488 (GPIB) and RS-232 |
| Model | UAF |
|---|
The Rohde & Schwarz UAF Video Test Set supports B/G, D/K, I, and M broadcast standards with three input channels, enabling accurate analysis of 29 video parameters. GPIB connectivity ensures seamless integration for automated testing setups.
Ideal for video signal verification, the UAF supports precise testing in production, service, and development environments with detailed parameter analysis for comprehensive diagnostics.
Testwall can supply the used Rohde & Schwarz UAF, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz UAF.
