LeCroy WaveMaster 806Zi
| Attribute | Value |
|---|---|
| Bandwidth | 6 GHz |
| Sample Rate | 20 GS/s (single channel), 10 GS/s (all channels) |
| Number of Channels | 4 |
| Memory Depth | 32 Mpts/Ch (standard), up to 256 Mpts/Ch (optional) |
| Vertical Resolution | 8 bits (up to 11 bits with enhanced resolution) |
| Input Impedance | 50 Ω or 1 MΩ |
| Display | 15.3-inch color LCD touchscreen |
| Timebase Range | 20 ps/div to 800 s/div |
| Trigger Types | Edge, Width, Pattern, Qualified, Runt, Slew Rate, Serial (optional) |
| Connectivity | USB, Ethernet (LAN), GPIB (optional) |
| Model | WaveMaster 806Zi |
|---|
The LeCroy WaveMaster 806Zi offers 6 GHz analog bandwidth and 40 GS/s sampling rate per channel, enabling accurate signal capture and detailed waveform analysis. Featuring 4 channels, 256 Mpts memory depth per channel, and advanced de-embedding and serial-data triggering, it ensures deep signal fidelity through DBI technology and X-Stream architecture.
Ideal for high-speed signal analysis, its MAUI touchscreen UI supports intuitive operation and accelerated data throughput for engineers in research and development or validation tasks.
Testwall can supply the used LeCroy WaveMaster 806Zi, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the LeCroy WaveMaster 806Zi.
