Philips PM5696
| Attribute | Value |
|---|---|
| Device Type | TV/Video Pattern Generator |
| Output Standards | PAL, NTSC |
| Video Output Channels | Multiple test pattern outputs including composite and component signals |
| Test Patterns | Color bars, crosshatch, dot pattern, gray scale, and other standard test patterns |
| Frequency Range | Up to 6 MHz video bandwidth |
| Output Impedance | 75 Ohms |
| Power Supply | 100-240V AC, 50/60 Hz |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Connector Types | BNC connectors for video signal outputs |
| Applications | Television broadcast testing, video equipment alignment, monitor calibration, and service/maintenance of video systems |
| Model | PM5696 |
|---|
The Philips PM5696 is a professional TV signal generator designed for engineers and service technicians. It provides precise analog test signals across multiple television standards with high accuracy and signal stability. Featuring multi-standard compatibility, a wide selection of test signals, and an easy-to-read interface, it ensures efficient diagnostics and alignment in demanding broadcast and service applications.
Its robust build and intuitive controls make it suitable for reliable use in television servicing, broadcasting setups, and engineering test environments, supporting accurate performance verification and troubleshooting tasks.
Testwall can supply the used Philips PM5696, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Philips PM5696.
