Rohde & Schwarz
Rohde & Schwarz GNSS
GNSS Simulator for the SMBV100A Vector Signal Generator
GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS Supported GNSS Systems
L1, L2, L5 (multi-band support) Frequency Bands
Real-time GNSS signal simulation and generation Signal Simulation Capability
Sub-meter to centimeter level depending on configuration Positioning Accuracy
Up to 72 parallel tracking channels Number of Channels
| Attribute | Value |
|---|---|
| Supported GNSS Systems | GPS, GLONASS, Galileo, BeiDou, QZSS, SBAS |
| Frequency Bands | L1, L2, L5 (multi-band support) |
| Signal Simulation Capability | Real-time GNSS signal simulation and generation |
| Positioning Accuracy | Sub-meter to centimeter level depending on configuration |
| Number of Channels | Up to 72 parallel tracking channels |
| Interface | USB, LAN (Ethernet), GPIB, RS-232 |
| Output Power Range | -65 dBm to -130 dBm (adjustable) |
| Timing Accuracy | ±10 ns RMS synchronization accuracy |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Power Supply | 100–240 V AC, 50/60 Hz |
Rohde & Schwarz GNSS Options:
- R&S®SMBV100A - SMBV-B103 - Frequency up to 3.2 GHz
- R&S®SMBV100A - SMBV-B10 - Baseband generator
- R&S®SMBV100A - SMBV-B92 - Hard disk
- R&S®SMBV100A - SMBV-K44 - GPS
- R&S®SMBV100A - SMBV-K66 - Galileo
- R&S®SMBV100A - SMBV-K94 - Glonass
- R&S®SMBV100A - SMBV-K92 - GNSS enhanced
- R&S®SMBV100A - SMBV-K91 - Extension to 12 satellites
- R&S®SMBV100A - SMBV-K96 - Extension to 24 satellites
- R&S®SMBV100A - SMBV-K110 - SBAS
- R&S®SMBV100A - SMBV-K102 - Antenna pattern
- R&S®SMBV100A - SMBV-K360 - ERA-Glonass test suite
- R&S®SMBV100A - SMBV-K361 - eCall test suite
| Model | GNSS |
|---|
The Rohde and Schwarz GNSS simulator for the R&S®SMBV100A redefines satellite signal simulation with precise GNSS receiver testing, multifaceted vector signal generation, and real-world condition replication. Its modular design supports R&D and production needs.
Users benefit from customizable simulation scenarios, ideal for rigorous development environments and seamless integration into testing workflows.
Testwall can supply the used Rohde and Schwarz GNSS, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde and Schwarz GNSS.
