Rohde & Schwarz RTB2004
| Attribute | Value |
|---|---|
| Bandwidth | 200 MHz |
| Number of Channels | 4 Analog Channels |
| Sample Rate | 2.5 GSa/s |
| Memory Depth | 20 Mpts (40 Mpts with memory extension option) |
| Vertical Resolution | 10-bit ADC (up to 16-bit with high-resolution mode) |
| Display | 10.1-inch capacitive touchscreen, 1280 x 800 resolution |
| Digital Channels | 16 Digital Channels (with optional logic probe) |
| Waveform Update Rate | Up to 50,000 waveforms per second |
| Input Impedance | 1 MΩ || 15 pF |
| Interfaces | USB, Ethernet (LAN), HDMI output |
Rohde & Schwarz RTB2004 Options:
- RTB2004 - RTB-B241 - Upgrade of R&S®RTB2004 oscilloscopes to 100 MHz bandwidth
- RTB2004 - RTB-B242 - Upgrade of R&S®RTB2004 oscilloscopes to 200 MHz bandwidth
- RTB2004 - RTB-B243 - Upgrade of R&S®RTB2004 oscilloscopes to 300 MHz bandwidth
- RTB2004 - RTB-B1 - Mixed signal option for non-MSO models, 300 MHz
- RTB2004 - RTB-B6 - Arbitrary waveform generator
- RTB2004 - RTB-K1 - I²C/SPI serial triggering and decoding
- RTB2004 - RTB-K2 - UART/RS-232/RS-422/RS-485 serial triggering and decoding
- RTB2004 - RTB-K3 - CAN/LIN serial triggering and decoding
- RTB2004 - RTB-K15 - History and segmented memory
- RTB2004 - RTB-PK1 - Application package (-K1, -K2, -K3, -K15)
| Model | RTB2004 |
|---|
The Rohde & Schwarz RTB2004 (RTB2K-74) is a 70MHz, 4-channel digital oscilloscope combining advanced measurement tools like a logic analyzer, protocol analyzer, waveform and pattern generator, and digital voltmeter. It features a 10.1" capacitive touchscreen with 1280x800 resolution and gesture support, 10-bit ADC, and up to 20Msample memory. Fast sampling at 1.25Gsample/s and SmartGrid customizable display enhance its versatility.
Ideal for university labs and embedded system troubleshooting, the RTB2004 provides 50000 waveforms/s update rate, 1mV/div sensitivity, rich math functions including FFT, and comprehensive trigger modes with remote connectivity via USB, LAN, and web server.
Testwall can supply the used Rohde & Schwarz RTB2004, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz RTB2004.
