Rohde & Schwarz FSV40N
10Hz to 40GHz Signal and Spectrum Analyser
10 Hz to 40 GHz Frequency Range
-165 dBm (typ.) at 1 GHz with preamplifier Displayed Average Noise Level (DANL)
-116 dBc/Hz at 10 kHz offset from 1 GHz carrier Phase Noise
1 Hz to 50 MHz Resolution Bandwidth (RBW)
+20 dBm (typ.) at 1 GHz Third-Order Intercept Point (TOI)
| Attribute | Value |
|---|---|
| Frequency Range | 10 Hz to 40 GHz |
| Displayed Average Noise Level (DANL) | -165 dBm (typ.) at 1 GHz with preamplifier |
| Phase Noise | -116 dBc/Hz at 10 kHz offset from 1 GHz carrier |
| Resolution Bandwidth (RBW) | 1 Hz to 50 MHz |
| Third-Order Intercept Point (TOI) | +20 dBm (typ.) at 1 GHz |
| Maximum Input Power (RF) | +30 dBm (1 W) continuous |
| Sweep Time | 1 ms to 16000 s (span > 0) |
| Input Impedance | 50 Ω |
| Display | 12.1-inch XGA color touchscreen display (1024 × 768 resolution) |
| Interfaces / Connectivity | USB, LAN (1000BASE-T), GPIB (optional), HDMI output |
Rohde & Schwarz FSV40N Options:
- FSW - B4 - OCXO Precision Frequency Reference
- FSW - B8 - Resolution Bandwidth > 10 MHz (for FSW8/13/26)
- FSW - B8 - Resolution Bandwidth > 10 MHz (for FSW43/50/67, export license required)
- FSW - B10 - External Generator Control
- FSW - B13 - Highpass Filter for Harmonic Measurements
- FSW - B17 - Digital Baseband Interface
- FSW - B18 - Spare Solid State Drive / Removable Hard Drive (for FSW8/13/26/43/50)
- FSW - B18 - Spare Solid State Drive / Removable Hard Drive (for FSW67)
- FSW - B21 - LO/IF Connections for External Mixers (for FSW26)
- FSW - B21 - LO/IF Connections for External Mixers (for FSW43/50/67)
- FSW - B21 - LO/IF Connections for External Mixers (for FSW85)
- FSW - B24 - RF Preamplifier, 100 kHz to 13.6 GHz (for FSW8/13)
- FSW - B24 - RF Preamplifier, 100 kHz to 26.5 GHz (for FSW26)
- FSW - B24 - RF Preamplifier, 100 kHz to 43.5 GHz (for FSW43/67)
- FSW - B24 - RF Preamplifier, 100 kHz to 50 GHz, model .49 (for FSW50)
- FSW - B24 - RF Preamplifier, 100 kHz to 50 GHz, model .51 (for FSW50, export license required)
- FSW - B24 - RF Preamplifier, 100 kHz to 67 GHz (for FSW67, export license required)
- FSW - B25 - Electronic Attenuator, 1 dB steps (for FSW8/13/26)
- FSW - B28 - 28 MHz Analysis Bandwidth
- FSW - B33 - USB Mass Memory Write Protection
- FSW - B40 - 40 MHz Analysis Bandwidth
- FSW - B71 - Analog Baseband Inputs, 40 MHz Analysis Bandwidth (for FSW8/13)
- FSW - B71 - Analog Baseband Inputs, 40 MHz Analysis Bandwidth (for FSW26/43/50)
- FSW - B71 - Analog Baseband Inputs, 40 MHz Analysis Bandwidth (for FSW67)
- FSW - B71 - Analog Baseband Inputs, 40 MHz Analysis Bandwidth (for FSW85)
- FSW - B71E - 80 MHz Analysis Bandwidth for Analog Baseband Inputs (requires FSW-B71)
- FSW - B80 - 80 MHz Analysis Bandwidth
- FSW - B160 - 160 MHz Analysis Bandwidth
- FSW - B160R - Real-Time Spectrum Analyzer 160 MHz, POI ≤ 15 µs (export license required)
- FSW - B320 - 320 MHz Analysis Bandwidth
- FSW - B500 - 500 MHz Analysis Bandwidth
- FSW - B2000 - 2 GHz Analysis Bandwidth (for FSW26, ex-factory)
- FSW - B2000 - 2 GHz Analysis Bandwidth (for FSW43/50/67/85)
- FSW - K6 - Pulse Measurements
- FSW - K6S - Time Side Lobe Measurement (requires FSW-K6)
- FSW - K7 - Analog Modulation Analysis for AM/FM/φM
- FSW - K10 - GSM/EDGE/EDGE Evolution/VAMOS Measurements
- FSW - K17 - Multicarrier Group Delay Measurements
- FSW - K18 - Amplifier Measurements
- FSW - K30 - Noise Figure Measurements
- FSW - K33 - Security Write Protection of Solid State Drive
- FSW - K40 - Phase Noise Measurements
- FSW - K54 - EMI Measurements
- FSW - K60 - Transient Measurement Application
- FSW - K60H - Transient Hop Measurement (requires FSW-K60)
- FSW - K60C - Transient Chirp Measurement (requires FSW-K60)
- FSW - K70 - Vector Signal Analysis
- FSW - K72 - 3GPP FDD (WCDMA) BS Measurements incl. HSDPA and HSDPA+
- FSW - K73 - 3GPP FDD (WCDMA) MS Measurements incl. HSUPA and HSUPA+
- FSW - K76 - TD-SCDMA BS Measurements
- FSW - K77 - TD-SCDMA UE Measurements
- FSW - K82 - CDMA2000 BS Measurements
- FSW - K83 - CDMA2000 MS Measurements
- FSW - K84 - 1xEV-DO BS Measurements
- FSW - K85 - 1xEV-DO MS Measurements
- FSW - K91 - IEEE802.11a/b/g Measurements
- FSW - K91N - IEEE802.11n Measurements (requires FSW-K91)
- FSW - K91AC - IEEE802.11ac Measurements
- FSW - K91P - IEEE802.11p Measurements
- FSW - K100 - EUTRA/LTE FDD BS Measurements
- FSW - K101 - EUTRA/LTE TDD UE Measurements
- FSW - K102 - EUTRA/LTE BS MIMO Measurements
- FSW - K103 - EUTRA/LTE UL Advanced UL Measurements
- FSW - K104 - EUTRA/LTE TDD BS Measurements
- FSW - K105 - EUTRA/LTE TDD Uplink Measurements
- FSW - K192 - DOCSIS 3.1 OFDM Downstream (requires FSW-B320)
- FSW - K160RE - 160 MHz Real-Time Measurement Application, POI > 15 µs
- FSW - U21 - LO/IF Connections for External Mixers Upgrade (for FSW26)
- FSW - U40 - Analysis Bandwidth Upgrade from 28 MHz to 40 MHz
- FSW - U80 - Analysis Bandwidth Upgrade from 40 MHz to 80 MHz
- FSW - U160 - Analysis Bandwidth Upgrade from 80 MHz to 160 MHz
- FSW - U160R - Real-Time Spectrum Analyzer 160 MHz, POI ≤ 15 µs (export license required)
- FSW - U320 - Analysis Bandwidth Upgrade from 160 MHz to 320 MHz
- FSW - U500 - Analysis Bandwidth Upgrade from 80 MHz to 500 MHz
- FSW - U2000 - Upgrade to 2 GHz Signal Analysis Bandwidth (for FSW26)
- FSW - U2000 - Upgrade to 2 GHz Signal Analysis Bandwidth (for FSW50, serial number < 103080)
- FSW - U2000 - Upgrade to 2 GHz Signal Analysis Bandwidth (for FSW67, serial number < 103205)
| Model | FSV40N |
|---|
The Rohde & Schwarz FSV40N is a high-performance, user-friendly signal and spectrum analyzer featuring a frequency range up to 40 GHz and 160 MHz signal analysis bandwidth. It offers excellent RF properties with measurement applications supporting GSM, LTE, WLAN, and more, and includes an OCXO precision timebase for enhanced accuracy.
Designed for development, production, and field service, it is five times faster than comparable analyzers and supports fast data-throughput with easy on-site upgrades and touch interface usability.
Testwall can supply the used Rohde & Schwarz FSV40N, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz FSV40N.
