Rohde & Schwarz RTO2004 Digital Oscilloscope
| Attribute | Value |
|---|---|
| Bandwidth | 200 MHz |
| Number of Channels | 4 |
| Sample Rate | 10 Gsample/s |
| Memory Depth | 200 Mpoints (standard), up to 800 Mpoints (optional) |
| Vertical Resolution | 8-bit (up to 16-bit with high definition mode) |
| Display | 12.1-inch capacitive touchscreen, 1280 x 800 resolution |
| Waveform Update Rate | Up to 1,000,000 waveforms per second |
| Input Impedance | 50 Ω / 1 MΩ selectable |
| Time Base Range | 25 ps/div to 10,000 s/div |
| Connectivity & Interfaces | USB, LAN (Ethernet), GPIB (optional), DisplayPort |
Rohde & Schwarz RTO2004 Digital Oscilloscope Options:
- RTO2004 - RTO-B1 - Mixed Signal Option, 400 MHz (additional 16 logic channels)
- RTO2004 - RTO-B4 - OCXO 10 MHz (precision reference frequency with reference input and output connectors)
- RTO2004 - RTO-B10 - GPIB Interface
- RTO2004 - RTO-B19 - Additional Solid State Disk
- RTO2004 - RTO-B101 - Memory Upgrade, 100 Msample per channel
- RTO2004 - RTO-B102 - Memory Upgrade, 200 Msample per channel
- RTO2004 - RTO-B104 - Memory Upgrade, 400 Msample per channel
- RTO2004 - RTO-B110 - Memory Upgrade, 1 Gsample per channel
- RTO2004 - RTO-B201 - Upgrade of RTO2002/4 to 1 GHz bandwidth
- RTO2004 - RTO-B202 - Upgrade of RTO2002/4 to 2 GHz bandwidth
- RTO2004 - RTO-B203 - Upgrade of RTO2002/4 to 3 GHz bandwidth
- RTO2004 - RTO-B204 - Upgrade of RTO2004 to 4 GHz bandwidth
- RTO2004 - RTO-K1 - I2C/SPI Serial Decoding
- RTO2004 - RTO-K2 - UART/RS-232/RS-422/RS-485 Serial Decoding
- RTO2004 - RTO-K3 - CAN/LIN Serial Triggering and Decoding
- RTO2004 - RTO-K4 - FlexRay Serial Triggering and Decoding
- RTO2004 - RTO-K5 - I2S Serial Triggering and Decoding
- RTO2004 - RTO-K6 - MIL-STD-1553 Serial Triggering and Decoding
- RTO2004 - RTO-K7 - ARINC 429 Serial Triggering and Decoding
- RTO2004 - RTO-K8 - Ethernet Serial Decoding
- RTO2004 - RTO-K9 - CAN-FD Serial Triggering and Decoding
- RTO2004 - RTO-K10 - SENT Serial Triggering and Decoding
- RTO2004 - RTO-K11 - I/Q Software Interface
- RTO2004 - RTO-K12 - Jitter Analysis
- RTO2004 - RTO-K13 - Clock Data Recovery
- RTO2004 - RTO-K17 - High Definition Mode
- RTO2004 - RTO-K19 - Zone Trigger
- RTO2004 - RTO-K21 - USB 2.0 Compliance Test
- RTO2004 - RTO-K22 - Ethernet Compliance Test
- RTO2004 - RTO-K31 - Power Analysis
- RTO2004 - RTO-K40 - MIPI RFFE Serial Triggering and Decoding
- RTO2004 - RTO-K42 - MIPI D-PHY Serial Triggering and Decoding
- RTO2004 - RTO-K50 - Manchester and NRZ Serial Triggering and Decoding
- RTO2004 - RTO-K52 - 8b10b Serial Decoding
- RTO2004 - RTO-K55 - MDIO Serial Triggering and Decoding
- RTO2004 - RTO-K60 - USB 1.0/1.1/2.0/HSIC Serial Triggering and Decoding
- RTO2004 - RTO-K65 - SpaceWire Serial Triggering and Decoding
- RTO2004 - RTO-K92 - eMMC Compliance Test
| Model | RTO2004 |
|---|
The Rohde & Schwarz RTO2004 is a high-performance digital oscilloscope with 4 channels, offering a 600 MHz bandwidth and a 10 GSa/s sampling rate per channel. It features 50 MSa per channel memory, extendable to 200 MSa in single-channel mode.
Engineered for accuracy, it delivers low-noise measurements, 16-bit vertical resolution, and includes four 500 MHz passive voltage probes. Optional MSO 16 digital channels are available via the RTO-B1 module.
Testwall can supply the used Rohde & Schwarz RTO2004 Digital Oscilloscope, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz RTO2004 Digital Oscilloscope.
