Rohde & Schwarz SMATE200A
| Attribute | Value |
|---|---|
| Frequency Resolution | 0.01 Hz |
| Interfaces | GPIB, LAN, USB |
| Display | without display (external VGA) |
| Frequency Range | 100 kHz to 3 or 6 GHz |
| Output Power | -145 to +13 dBm (PEP, ≤ 3 GHz), +11 dBm (> 3 GHz) |
| SSB Phase Noise | < -131 dBc/Hz at 1 GHz, 20 kHz offset (-135 typ.) |
| Modulation | AM, FM, ΦM, I/Q, pulse |
| Level Accuracy | < 0.5 dB (1 MHz to 3 GHz), < 0.9 dB (> 3 GHz) |
| Non-Harmonics | < -77 dBc (0.3 to 200 MHz), < -90 dBc (200 to 1500 MHz), < -84 dBc (1.5 to 3 GHz) |
| Switching Speed | < 1 ms (0.6 ms typ.); < 400 µs list mode |
| Modulation Bandwidth | 200 MHz RF bandwidth (I/Q modulator), 40 MHz internal baseband |
| Sweep Modes | step sweep, power sweep, list mode |
| Timebase Aging | 1 × 10⁻⁷ per year, 1 × 10⁻⁹ per day |
Rohde & Schwarz SMATE200A Options:
- SMATE200A - SMATE-B103 - RF Path A, 100 kHz to 3 GHz
- SMATE200A - SMATE-B106 - RF Path A, 100 kHz to 6 GHz
- SMATE200A - SMATE-B22 - Low Phase Noise and analog modulation FM/ΦM
- SMATE200A - SMATE-B31 - High-Power Output (RF Path A)
- SMATE200A - SMATE-B203 - RF Path B, 100 kHz to 3 GHz
- SMATE200A - SMATE-B206 - RF Path B, 100 kHz to 6 GHz
- SMATE200A - SMATE-B36 - High-Power Output (RF Path B)
- SMATE200A - SMATE-B10 - Baseband Generator with ARB (64 Msamples) and Digital Modulation (realtime)
- SMATE200A - SMATE-B11 - Baseband Generator with ARB (16 Msamples) and Digital Modulation (realtime)
- SMATE200A - SMATE-B13 - Baseband Main Module
- SMATE200A - SMATE-B16 - Differential I/Q Output
- SMATE200A - SMATE-K40 - Digital Standard GSM/EDGE
- SMATE200A - SMATE-K42 - Digital Standard 3GPP FDD
- SMATE200A - SMATE-K43 - 3GPP Enhanced MS/BS Tests incl. HSDPA
- SMATE200A - SMATE-K44 - Digital Standard GPS
- SMATE200A - SMATE-K46 - Digital Standard CDMA2000® incl. 1×EV-DV
- SMATE200A - SMATE-K48 - Digital Standard IEEE 802.11 (a/b/g)
- SMATE200A - SMATE-K49 - Digital Standard IEEE 802.16 (d)
- SMATE200A - SMATE-K61 - Multicarrier CW Signal Generation
- SMATE200A - SMATE-K11 - Digital Standard IS-95 (with WinIQSIM™)
- SMATE200A - SMATE-K12 - Digital Standard CDMA2000® (with WinIQSIM™)
- SMATE200A - SMATE-K13 - Digital Standard 3GPP TDD (with WinIQSIM™)
- SMATE200A - SMATE-K14 - Digital Standard TD-SCDMA (with WinIQSIM™)
- SMATE200A - SMATE-K15 - User-Defined OFDM Signals (with WinIQSIM™ and WinIQOFDM)
- SMATE200A - SMATE-K17 - Digital Standard 1xEV-DO (with WinIQSIM™)
- SMATE200A - SMATE-K19 - Digital Standard IEEE 802.11 (a/b/g) (with WinIQSIM™)
- SMATE200A - SMATE-K20 - Digital Standard 3GPP FDD incl. HSDPA (with WinIQSIM™)
- SMATE200A - SMATE-K5 - Bluetooth® (with external software)
- SMATE200A - SMATE-K62 - Additive White Gaussian Noise (AWGN)
The Rohde & Schwarz SMATe200A Vector Signal Generator is a compact, rack-mountable 2U device supporting frequencies from 100 kHz to 6 GHz. It ensures high spectral purity and low phase noise (–135 dBc/Hz at 1 GHz) with fast frequency and level switching, essential for automated testing. With up to 160 MHz internal I/Q modulation bandwidth, the unit supports diverse digital modulation types including QAM, PSK, FSK, and custom I/Q waveforms.
Designed for R&D and production use, it integrates seamlessly into test systems via USB, LAN, or GPIB. Its intuitive interface and compact size make it ideal for wireless and broadcasting test setups.
Testwall can supply the used Rohde & Schwarz SMATe200A, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz SMATe200A.
Options and configurations
- Frequency Range: 100 kHz to 3 or 6 GHz (Opt. B103/B106, path A; B203/B206, path B)
- Output Power: -145 to +13 dBm (PEP, ≤ 3 GHz), +11 dBm (> 3 GHz); +19/+17 dBm with Opt. B31/B36
- SSB Phase Noise: < -131 dBc/Hz at 1 GHz, 20 kHz offset (-135 typ.); < -136 dBc/Hz with Opt. B22
- Modulation: AM, FM, ΦM (Opt. B22), I/Q, pulse
