Rohde & Schwarz SML02
| Attribute | Value |
|---|---|
| Frequency Range | 9 kHz to 2.2 GHz |
| Level Accuracy | < 0.5 dB (to 2 GHz) |
| Frequency Resolution | 0.1 Hz |
| Harmonics | < -30 dBc |
| Switching Speed | < 10 ms |
| Output Power | -140 to +13 dBm |
| SSB Phase Noise | < -122 dBc/Hz at 1 GHz, 20 kHz offset |
| Modulation | AM, FM, ΦM, pulse |
| Non-Harmonics | < -70 dBc (to 1.1 GHz), < -64 dBc (1.1 to 2.2 GHz) |
| Interfaces | GPIB, RS-232 |
The Rohde & Schwarz SML02 Signal Generator offers a wide frequency range from 9 kHz to 2.2 GHz with a 0.1 Hz resolution and signal levels ranging from -140 dBm to +19 dBm. It delivers exceptional signal purity with SSB phase noise under -122 dBc/Hz and fast setting times below 10 ms. Equipped with AM, FM, Phase Modulation, and optional pulse modulation, this unit ensures superior modulation capabilities.
Ideal for RF testing, it includes high level accuracy (<0.5 dB), digital frequency/level sweep, and interfaces such as GPIB and RS-232. A reliable electronic attenuator enhances long-term performance.
Testwall can supply the used Rohde & Schwarz SML02 Signal Generator, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Rohde & Schwarz SML02 Signal Generator.
Options and configurations
- Output Power: -140 to +13 dBm (+23 dBm with Opt. SML-B10)
- Modulation: AM, FM, ΦM, pulse (Opt. SML-B3)
