Stanford Research
Stanford Research SIM918
22KHz Current Amplifier
±10 V Voltage Range
1 mV (20-bit DAC) Resolution
±20 mA maximum Output Current
4 independent DC voltage outputs Number of Output Channels
<10 µV RMS (10 Hz bandwidth) Output Noise
| Attribute | Value |
|---|---|
| Voltage Range | ±10 V |
| Resolution | 1 mV (20-bit DAC) |
| Output Current | ±20 mA maximum |
| Number of Output Channels | 4 independent DC voltage outputs |
| Output Noise | <10 µV RMS (10 Hz bandwidth) |
| Temperature Coefficient | 25 ppm/°C |
| Interface | SIM (Small Instrumentation Modules) bus interface |
| Power Requirements | Powered via SIM900 mainframe backplane |
| Operating Temperature | 0°C to 40°C |
| Module Form Factor | Single-wide SIM module |
| Model | SIM918 |
|---|
The Stanford Research Systems SIM918 is a 22.00 KHz Current Amplifier
