Tektronix 1765
NTSC/PAL Component Waveform/Vector Monitor
2 Channels Channels
100 MHz Bandwidth
200 MS/s Maximum Sample Rate
15,000 Points Record Length
8 Bits Vertical Resolution
| Attribute | Value |
|---|---|
| Channels | 2 Channels |
| Bandwidth | 100 MHz |
| Maximum Sample Rate | 200 MS/s |
| Record Length | 15,000 Points |
| Vertical Resolution | 8 Bits |
| Vertical Sensitivity | 2 mV/div to 5 V/div |
| Time Base Range | 5 ns/div to 5 s/div |
| Input Impedance | 1 MΩ in parallel with 20 pF |
| Display Type | Monochrome CRT Display |
| Power Requirements | 100 to 240 VAC, 50/60 Hz |
Tektronix 1765 Options:
- 1765 - Option 74 - White CRT Phosphor for any model
- 1765 - Option SC - SCH/Color Framing option for 1760/1761/1765
| Model | 1765 |
|---|
The Tektronix 1765 is a robust waveform monitor designed for PAL composite signal analysis. It features dual-channel display, adjustable graticule brightness, and both horizontal and vertical magnification for precise signal monitoring.
Ideal for broadcast engineers, the Tektronix 1765 ensures accurate video signal integrity, supporting external reference input for synchronization.
Testwall can supply the used Tektronix 1765, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix 1765.
