Tektronix AM5030S
Current Measurement System DC - 100 MHz
AC: 100 mA to 30 A RMS; DC: 100 mA to 30 A Current Measurement Range
DC to 50 MHz (-3 dB) Bandwidth
AC/DC Current Probe Current Probe Type
10 mV/A, 100 mV/A (selectable) Sensitivity
10 mm Maximum Conductor Diameter
| Attribute | Value |
|---|---|
| Current Measurement Range | AC: 100 mA to 30 A RMS; DC: 100 mA to 30 A |
| Bandwidth | DC to 50 MHz (-3 dB) |
| Current Probe Type | AC/DC Current Probe |
| Sensitivity | 10 mV/A, 100 mV/A (selectable) |
| Maximum Conductor Diameter | 10 mm |
| Peak Current Rating | 50 A peak (non-repetitive) |
| Output Connector | BNC |
| Power Requirements | Powered via AM503B or TM500/TM5000 series mainframe |
| Operating Temperature Range | 0°C to +50°C |
| Accuracy | ±2% DC accuracy at full scale |
Tektronix AM5030S Options:
- AM5030S - A0 - North America power
- AM5030S - A1 - Universal EURO power
- AM5030S - A2 - United Kingdom power
- AM5030S - A3 - Australia power
- AM5030S - A4 - 240 V, North America power
- AM5030S - A5 - Switzerland power
- AM5030S - C3 - Calibration Service 3 Years
- AM5030S - C5 - Calibration Service 5 Years
- AM5030S - D1 - Calibration Data Report
- AM5030S - D3 - Calibration Data Report 3 Years (with Opt. C3)
- AM5030S - D5 - Calibration Data Report 5 Years (with Opt. C5)
- AM5030S - R3 - Repair Service 3 Years
- AM5030S - R5 - Repair Service 5 Years
| Model | AM5030S |
|---|
The Tektronix AM5030S Current Probe Amplifier System delivers precision current measurement with ±0.5% accuracy. It seamlessly integrates with A6302 and A6303 probes, offering compatibility with TDS oscilloscopes. Designed in a compact mainframe housing, it is ideal for both low-level and pulsed current analysis.
This system enhances testing capabilities in electronic diagnostics and R&D labs, providing clean signal amplification and versatile setup options.
Testwall can supply the used Tektronix AM5030S, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix AM5030S.
