Tektronix BA1500 Pattern Generator and Error Analyzer 1.5 Gb/s
| Attribute | Value |
|---|---|
| Maximum Bit Rate | 1.5 Gb/s |
| Minimum Bit Rate | 50 Mb/s |
| Pattern Length | Up to 2^23 - 1 bits (PRBS) and programmable patterns up to 8 Mb |
| Output Amplitude | 0.25 V to 2.0 V peak-to-peak (into 50 Ω) |
| Output Impedance | 50 Ω |
| Jitter Injection | Sinusoidal jitter injection capability for stress testing |
| Error Detection | Built-in Bit Error Rate (BER) measurement with error counting and ratio analysis |
| Clock Reference | Internal and external clock reference supported |
| Interface | GPIB and RS-232 remote control interfaces |
| Input Sensitivity | Adjustable threshold levels for data and clock inputs |
Tektronix BA1500 Pattern Generator and Error Analyzer 1.5 Gb/s Options:
- BA1500 - PL - Add Physical Layer Test Suite, MAP (Error Mapping analysis), and ECC (Error Correction Coding emulation)
| Model | BA1500 |
|---|
The Tektronix BitAlyzer BA Series delivers bit error rate testing up to 1.6 Gb/s with PRBS and user-defined patterns, ANSI jitter analysis, and advanced BER visualization tools. Includes adjustable amplitude, clock source, and differential/single-ended I/O to evaluate signal integrity in complex communication systems.
Perfect for semiconductor testing, satellite and wireless communication systems, and fiber optic validation, featuring FEC emulation, error mapping, and intuitive eye diagram analysis tools.
Testwall can supply the used Tektronix BitAlyzer BA Series, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix BitAlyzer BA Series.
