Tektronix BSA12500ISI
| Attribute | Value |
|---|---|
| Data Rate | Up to 12.5 Gb/s |
| Number of Channels | 4 electrical channels |
| Optical Module Support | Compatible with optical sampling modules for multi-rate optical signal analysis |
| Timebase Accuracy | ±1 ppm |
| Jitter Measurement Floor | Less than 100 fs RMS random jitter measurement floor |
| Vertical Resolution | 8-bit vertical resolution |
| Trigger Input | External trigger input with wide frequency range support |
| Compliance Testing | Supports serial data compliance testing including SONET/SDH, Fibre Channel, Ethernet, and PCI Express standards |
| Interface | GPIB, USB, and LAN connectivity for remote control and data transfer |
| Display | High-resolution color display with advanced eye diagram and waveform analysis capabilities |
| Model | BSA12500ISI |
|---|
The Tektronix BSA12500ISI BERT/Jitter Test System is engineered for precise evaluation of high-speed serial data interfaces, offering Bit Error Rate Testing (BERT) and jitter analysis across 1 Gbps to 40 Gbps. It supports electrical, optical, and differential inputs with features like clock recovery and eye diagram analysis.
Engineers in R&D, manufacturing, and compliance benefit from its advanced signal integrity capabilities across standards like PCIe, USB, and Ethernet.
Testwall can supply the used Tektronix BSA12500ISI, fully tested. With expert support and global delivery, Testwall ensures high-performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix BSA12500ISI.
