Tektronix DPO4034B
| Attribute | Value |
|---|---|
| Bandwidth | 350 MHz |
| Number of Channels | 4 |
| Sample Rate | 2.5 GS/s |
| Record Length | 20 M points |
| Vertical Resolution | 8-bit (11-bit with Hi Res mode) |
| Rise Time | 1 ns |
| Input Impedance | 1 MΩ or 50 Ω |
| Display | 10.4-inch WVGA (800 x 480) color display |
| Waveform Capture Rate | Up to 340,000 waveforms per second |
| Connectivity | USB, Ethernet, CompactFlash |
Tektronix DPO4034B Options:
- DPO4034B - A0 - North America power plug (115 V, 60 Hz)
- DPO4034B - A1 - Universal Euro power plug (220 V, 50 Hz)
- DPO4034B - A2 - United Kingdom power plug (240 V, 50 Hz)
- DPO4034B - A3 - Australia power plug (240 V, 50 Hz)
- DPO4034B - A5 - Switzerland power plug (220 V, 50 Hz)
- DPO4034B - A6 - Japan power plug (100 V, 50/60 Hz)
- DPO4034B - A10 - China power plug (50 Hz)
- DPO4034B - A11 - India power plug (50 Hz)
- DPO4034B - A12 - Brazil power plug (60 Hz)
- DPO4034B - A99 - No power cord
- DPO4034B - L0 - English manual
- DPO4034B - L1 - French manual
- DPO4034B - L2 - Italian manual
- DPO4034B - L3 - German manual
- DPO4034B - L4 - Spanish manual
- DPO4034B - L5 - Japanese manual
- DPO4034B - L6 - Portuguese manual
- DPO4034B - L7 - Simplified Chinese manual
- DPO4034B - L8 - Traditional Chinese manual
- DPO4034B - L9 - Korean manual
- DPO4034B - L10 - Russian manual
- DPO4034B - L99 - No manual
- DPO4034B - C3 - Calibration Service 3 Years
- DPO4034B - C5 - Calibration Service 5 Years
- DPO4034B - D1 - Calibration Data Report
- DPO4034B - D3 - Calibration Data Report 3 Years (with Opt. C3)
- DPO4034B - D5 - Calibration Data Report 5 Years (with Opt. C5)
- DPO4034B - R5 - Repair Service 5 Years (including warranty)
- DPO4034B - SILV600 - Standard warranty extended to 5 years
- DPO4034B - DPO4BND - Application bundle module enabling all functionality of DPO4AERO, DPO4AUDIO, DPO4AUTO, DPO4COMP, DPO4EMBD, DPO4ENET, DPO4LMT, DPO4PWR, DPO4USB and DPO4VID application modules in a single module
- DPO4034B - DPO4AERO - Aerospace Serial Triggering and Analysis Module (MIL-STD-1553)
- DPO4034B - DPO4AUDIO - Audio Serial Triggering and Analysis Module (I2S, LJ, RJ, TDM)
- DPO4034B - DPO4AUTO - Automotive Serial Triggering and Analysis Module (CAN, LIN)
- DPO4034B - DPO4AUTOMAX - Extended Automotive Serial Triggering and Analysis Module (CAN, LIN, FlexRay)
- DPO4034B - DPO4COMP - Computer Serial Triggering and Analysis Module (RS-232/422/485/UART)
- DPO4034B - DPO4EMBD - Embedded Serial Triggering and Analysis Module (I2C, SPI)
- DPO4034B - DPO4ENET - Ethernet Serial Triggering and Analysis Module (10BASE-T, 100BASE-TX)
- DPO4034B - DPO4USB - USB Serial Triggering and Analysis Module (low-speed, full-speed, high-speed)
- DPO4034B - DPO4PWR - Power Analysis Application Module
- DPO4034B - DPO4LMT - Limit and Mask Testing Application Module
- DPO4034B - DPO4VID - HDTV and Custom (nonstandard) Video Triggering and Video Picture Module
| Model | DPO4034B |
|---|
The Tektronix DPO4034B Digital Phosphor Oscilloscope delivers up to 20‑channel analog/digital signal analysis with high bandwidth, deep memory, advanced triggering, Wave Inspector® navigation, FFT analysis, a 10.4″ XGA display and TekVPI® probe interface for seamless scaling and measurement.
It supports serial protocol decoding (I²C, SPI, USB, Ethernet, CAN, LIN, RS‑232/422/485/UART, MIL‑STD‑1553, I²S/LJ/RJ/TDM), features integrated Ethernet and USB ports, and offers optional modules for power analysis, limit‑mask testing, and HDTV/video inspection—perfect for comprehensive diagnostics.
Testwall can supply the used Tektronix DPO4034B Digital Phosphor Oscilloscope, fully tested. With expert support and global delivery, Testwall ensures high‑performance instrumentation with unmatched reliability and service quality. Please contact us directly if you need calibration or repair of the Tektronix DPO4034B Digital Phosphor Oscilloscope.
